Aluminum Fin/Copper Tube Evaporator for Cold Room Storage

PRIMARY PARAMETERS

Model NO.

EST

Warranty

1-2 Years

Certification

Condition

New

Power Supply

380V-50Hz,Others Are Optional

Color

White

OEM

Available

Ss Casing

Optional

Trademark

EUROSTARS

Transport Package

Standard Export Package

Specification

Origin

China

HS Code

8418692090

DETAIL DESCRIPTION

1.General Introduction -air cooler or evaporator for cold storage or cold room
We EUROSTARS have 3 kinds of typical air cooler(evaporator) which been widely used for the
different refrigerated room or cold room,cold storage.It is a indoor cooling
equipment which need connect with outdoor freon condensing unit.
**ESTJS: 0ºC keeping-fresh room;
**ESTKS: -18ºC refrigerating room;
**ESTXS:-25ºC fast refrigerating room;

2.Unit Features-air cooler or evaporator

1)With steel plate coating casing,corrosion-proof,attractive appearance;
2)Aluminum fins around mechanically expanded copper tube make the coil with high efficiency heat exchange;
3)Configurated stainless steel electrically heating pipe with high defrosting efficiency;
4)Double water collector configurated to avoid water collector being freezed;
5)Long distance air duct is optional;
6)Standard power supply is 380V-3PH-50HZ,and other kinds of power supply is optional;
7)Stainless steel casing is optional.

3.Detailed Parameter-air cooler or evaporator

ESTJS Series Air Cooler Technical Parameter(fin space 4.5mm)

Model	Cooling Capacity KW	Air Flow	Air throw	Fan Dia.	Fan Qty	Fan Power	Defrosting Power(KW)
DT=7K,t0=-25ºC
R22	R404A	m3/h	m	cm	pcs	W	coil	water collector
EST-2.3JS	2.2	2.3	1500	9	31	1	90	1	0.5
EST-3.7JS	3.5	3.7	1500	9	31	1	90	1.5	0.5
EST-4.9JS	4.7	4.9	3000	9	31	2	180	2.7	0.9
EST-6.3JS	6	6.3	3000	9	31	2	180	3.6	0.9
EST-9.5JS	9	9.5	4500	10	35	2	280	3.6	1.2
EST-13.1JS	12.5	13.1	7000	13	40	2	360	4.8	1.2
EST-15.2JS	14.5	15.2	7000	13	40	2	360	6	1.2
EST-17.9JS	17	17.9	7000	13	40	2	360	6	1.2
EST-26.3JS	25	26.3	12000	17	50	2	900	7.5	3
EST-30.5JS	29	30.5	13500	17	45	3	750	10	4
EST-38.3JS	36.5	38.3	18000	19	50	3	1350	10	4
EST-44.1JS	42	44.1	18000	19	50	3	1350	12	4
EST-51.5JS	49	51.5	18000	19	50	3	1350	12	4
EST-62JS	59	62	24000	19	50	4	1800	15.6	5.2
EST-73.5JS	70	73.5	30000	25	55	4	2400	15.6	5.2
EST-88.2JS	84	88.2	30000	25	55	4	2400	23.4	5.2
EST-108.2JS	103	108.2	42000	25	60	4	3120	26	5.2
EST-117.6JS	112	117.6	46000	25	63	4	3200	31.2	5.2
EST-128.1JS	122	128.1	46000	28	63	4	3200	33.8	5.2

ESTKS Series Air Cooler Technical Parameter(fin space 6.0mm)

Model	Cooling Capacity KW	Air Flow	Air throw	Fan Dia.	Fan Qty	Fan Power	Defrosting Power(KW)
DT=7K,t0=-7ºC
R22	R404A	m3/h	m	cm	pcs	W	coil	water collector
EST-1.5KS	1.4	1.5	1500	9	31	1	90	1	0.5
EST-2.4KS	2.3	2.4	1500	9	31	1	90	1.5	0.5
EST-3.2KS	3	3.2	3000	9	31	2	180	2.7	0.9
EST-4.7KS	4.5	4.7	3000	9	31	2	180	3.6	0.9
EST-6.3KS	6	6.3	4500	10	35	2	280	3.6	1.2
EST-7.9KS	7.5	7.9	7000	13	40	2	360	4.8	1.2
EST-9.5KS	9	9.5	7000	13	40	2	360	6	1.2
EST-11.6KS	11	11.6	7000	13	40	2	360	6	1.2
EST-16.3KS	15.5	16.3	12000	17	50	2	900	7.5	3
EST-20KS	19	20	13500	17	45	3	750	10	4
EST-25.2KS	24	25.2	18000	19	50	3	1350	10	4
EST-30.5KS	29	30.5	18000	19	50	3	1350	12	4
EST-33.6KS	32	33.6	18000	19	50	3	1350	12	4
EST-39.9KS	38	39.9	24000	19	50	4	1800	15.6	5.2
EST-49.4KS	47	49.4	30000	25	55	4	2400	15.6	5.2
EST-60.9KS	58	60.9	30000	25	55	4	2400	23.4	5.2
EST-75.6KS	72	75.6	42000	25	60	4	3120	26	5.2
EST-83KS	79	83	46000	25	63	4	3200	31.2	5.2
EST-92.4KS	88	92.4	46000	28	63	4	3200	33.8	5.2

ESTXS Series Air Cooler Technical Parameter(fin space 9.0mm)

Model	Cooling Capacity KW	Air Flow	Air throw	Fan Dia.	Fan Qty	Fan Power	Defrosting Power(KW)
DT=7K,t0=-7ºC
R22	R404A	m3/h	m	cm	pcs	W	coil	water collector
EST-1.8XS	1.7	1.8	1500	9	31	1	90	1.5	0.5
EST-2.3XS	2.2	2.3	3000	9	31	2	180	2.7	0.9
EST-2.8XS	2.7	2.8	3000	9	31	2	180	3.6	0.9
EST-4.4XS	4.2	4.4	4500	10	35	2	280	3.6	1.2
EST-5.9XS	5.6	5.9	7000	13	40	2	360	4.8	1.2
EST-7.1XS	6.8	7.1	7000	13	40	2	360	6	1.2
EST-8.2XS	7.8	8.2	7000	13	40	2	360	6	1.2
EST-12.1XS	11.5	12.1	12000	17	50	2	900	7.5	3
EST-14.7XS	14	14.7	13500	17	45	3	750	10	4
EST-17.9XS	17	17.9	18000	19	50	3	1350	10	4
EST-21XS	20	21	18000	19	50	3	1350	12	4
EST-24.2XS	23	24.2	18000	19	50	3	1350	12	4
EST-27.3XS	26	27.3	24000	19	50	4	1800	15.6	5.2
EST-32.6XS	31	32.6	30000	25	55	4	2400	15.6	5.2
EST-60.9XS	40	42	30000	25	55	4	2400	23.4	5.2
EST-75.6XS	49	51.5	42000	25	60	4	3120	26	5.2
EST-83XS	53.6	56	46000	25	63	4	3200	31.2	5.2
EST-92.4XS	58	61	46000	28	63	4	3200	33.8	5.2
