★Product Brief
Particularly it is suitable for granulating, pelleting and coating of various varieties in pharmaceutical industry, foodstuff industry and chemical industry New product research and development,colleges and universities teaching and scientific research etc.
★ Features of equipment
Multi-function such as granulating, pelleting, coating in one machine.
1.Powder material granulating.
2.Powder material coating.
3.Powder material pelleting.
4.Chinese medicine spray drying, granulating and coating.
5.Make 10-30 meshes big granule.
6.Film coating of Powder, granules and pellets, enteric release, slow and control release coating.
7.Taste masking, odor, moistureproof, antioxidation, prevent water, heat insulation, coloration and separation coating
8.Powder, granule, agglomerate material drying.
★ General of applications
DLP Granulator/Coater/Pelleter is multi-function equipment integrated spray drying-granulating-centrifugal spray coating-fluid coating-drying in one body. The machine combined various process operations.
★ Technical parameters
Particularly it is suitable for granulating, pelleting and coating of various varieties in pharmaceutical industry, foodstuff industry and chemical industry New product research and development,colleges and universities teaching and scientific research etc.
★ Features of equipment
Multi-function such as granulating, pelleting, coating in one machine.
1.Powder material granulating.
2.Powder material coating.
3.Powder material pelleting.
4.Chinese medicine spray drying, granulating and coating.
5.Make 10-30 meshes big granule.
6.Film coating of Powder, granules and pellets, enteric release, slow and control release coating.
7.Taste masking, odor, moistureproof, antioxidation, prevent water, heat insulation, coloration and separation coating
8.Powder, granule, agglomerate material drying.
★ General of applications
DLP Granulator/Coater/Pelleter is multi-function equipment integrated spray drying-granulating-centrifugal spray coating-fluid coating-drying in one body. The machine combined various process operations.
★ Technical parameters
| Item | specification | ||||||||
| Name | Unit | DLP-10 | DLP-15 | DLP-20 | DLP-30 | DLP-45 | DLP-60 | DLP-90 | DLP-120 |
| Productive capacity | Kg/batch | 2.5-10 | 3-15 | 5-20 | 7.5-30 | 10-45 | 15-60 | 20-90 | 30-120 |
| Diameter of container | Mm | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1400 | 1500 |
| Power of fan | Kw | 7.5 | 11 | 11 | 11 | 15 | 15 | 18.5 | 18.5 |
| Noise | db | No more than 75db separated of fan | |||||||
| Compressed air | Pressure | Mpa | 0.6 | ||||||
| Consumption | M3 /min | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 1.4 | 1.4 |
| Steam | Pressure | Mpa | 0.4-0.6 | ||||||
| Consumption | M3 /min | 35 | 42 | 47 | 60 | 140 | 160 | 160 | 240 |
| Power of electrical heater | Kw | Design by client |
