Altaqua 10 ton water industrial chiller plant

for commercial applications, hotels, office buildings, apartment buildings, super markets, hospitals, schools and others.

Technical Feature

Brandnew

Air-Cooled, Air-cooled/water chiller/unit

Guangdong, China (Mainland)

Altaqua

35 kw/h

380V/3Ph/50Hz & others

Send Standard Inquiry

Add Inquiry List

$0~0

PRIMARY PARAMETERS

Condition

Brandnew

Type

Air-Cooled, Air-cooled/water chiller/unit

Place of Origin

Guangdong, China (Mainland)

Brand Name

Altaqua

Cooling Capability(kw)

35 kw/h

Voltage

380V/3Ph/50Hz & others

Dimension(L*W*H)

1650x900x1550 mm

Weight

295 kg

Certification

CE, ROHS, ISO9001

Warranty

12~36 Months

After-sales Service Provided

Overseas service center available

Refrigerant

R410a/R407c/R134a

Evaporator

Tube/shell/coil/plate/tank heat exchanger for choice

Compressor Brand

Panasonic/Copeland/Danfoss/Hitachi/Others

Inlet Water Temp

12 u2103

Outlet Water Temp

7 u2103

Power Input

11.6 kw/h

Flow Rate

2.5~6.0 l/s

Design Pressure Drop

40~60 kPa

Design Water Temp

5~25 u2103

DETAIL DESCRIPTION

Product Description

Altaqua Chiller supply economic air conditioning & heating solution for commercial applications, hotels, office buildings, apartment buildings, super markets, hospitals, schools and others.

Cooling capacity	5kw/hour ~ 700kw/hour & customized available
Power supply	220V/1p/50Hz, 380V/3p/50Hz & customized available
Refrigerant	R410a, R134a, R407c & customized available
Outlet water temperature	5 ~ 25 ℃ & customized available
