Applications & Features
- Apply high accuracy MEMS sensor and digital technologies, can measure positive, negative ordifferential pressure
- It can measure fan and blower pressures, filterresistance, air velocity, furnace draft, pressure drop across orifice plates, liquid levels of bubbler systems and pressure amplifier or hydraulic system, and in medical care equipment to monitorbloodand respiratory pressure
- Multiple ranges, engineering units and outputs
- Very high performance/price ratio, 1% or 2% accuracy
- Function keys: zero calibrate, unit select, response time set, etc
- Field upgradable LCD display module
Specifications
Medium: non-combustible, non-corrosive air, insensitive to moisture, dust, condensation and oil
Working Temp.: -20~70°C
Medium Temp.: 0-60°C
Compensated Temp.: 0-50°C
Working pressure: 1, 2, 5 or 10Kpa for different ranges, overload 10xFS, burst 15xFS
Process Connection: 1/8” ID tubing
Display: 5 digit LCD, with unit indication, field upgradable
Output: 0~10V, 4~20mA (2 wires), RS485 selectable
Output Load: ≤500Ω (current), ≥2KΩ (voltage)
Accuracy: DPT:±1.0%FS, DPTL:±2.0%FS
Long term stability: ±0.5%FS /Year
Temp. Drift: < 0.05%FS/°C
Response time: 0.5-30s, can be set by button keys
Power: 15~28V AC/15~36VDC
Protection: IP54
Unit select & Zero setting: by keys
Materials: ABS (housing) & PC (cover)
Approval: CE
Models
| Model | DPT | DP transmitter(±1.0%FS) | |||
DPTL | DP transmitter (±2.0%FS) | ||||
Range | See table | Ranges selection | |||
| Output | 1 2 8 |
| 0-10V 4-20mA (2 wires) RS485 | ||
Display |
| 0 1 | N/A LCD |
Embedded install panel(accessory):
316 stainless steel panel, for clean room embedded
installation, no duct and easy to clean
Dimensions:103(W)×91(H)×1.2(D)mm
Model:DPT-A (the picture below is for the combination of the panel and the transmitter)
Measuring ranges
| Code | UNIT & Ranges | |||||
| Pa | Pa | KPa | In W.C | mm W.C | mbar | |
| 1 | 0-60/125 | 60.00 | 0.060 | 0.250 | 6.000 | 0.600 |
| 125.0 | 0.125 | 0.500 | 12.00 | 1.250 | ||
| 3 | 0-250/500/1000 | 250.0 | 0.250 | 1.000 | 25.00 | 2.500 |
500.0 | 0.500 | 2.000 | 50.00 | 5.000 | ||
| 1000 | 1.000 | 4.000 | 100.0 | 10.00 | ||
| 7 | 0-2000 | 2000 | 2.000 | 8.000 | 200.0 | 20.00 |
| 8 | 0-3000 | 3000 | 3.000 | 12.00 | 300.0 | 30.00 |
| 9 | 0-5000 | 5000 | 5.000 | 20.00 | 500.0 | 50.00 |
| A | 0-10000 | 10000 | 10.00 | 40.00 | 1000 | 100.0 |
Note: 1. the code 1and 3 have two or three measuring ranges, selected by jumper
2. Set the 5 engineering units by button and related LCD indicator will be on
3. For zero center models, add “Z” at the end of the model. For example, DPT1**Z, means full range 60 or 125pa, but actual output is -30-0-30pa or -62.5-0-62.5pa respectively
Sample Order | Order | OEM Order |
| Three work days | 2 weeks | 3 weeks |
