DF type Horizontal centrifugal electric motor transfer no solid grain 304 316ss corrosive resisting flange coupling pump
DF type Horizontal centrifugal electric motor transfer no solid grain 304 316ss corrosive resisting flange coupling pump has compact structure, less vibration,high efficiency,mechanical seal,all parts touched with
water can be made of stainless steel.
DF type Horizontal centrifugal electric motor transfer no solid grain 304 316ss corrosive resisting flange coupling pump special in low pressure, all parts touch with liquid can be of stainless steel materials,cast iron materials is mainly for the clean water and physically chemically similar to clean water liquid,cast steel materials
is for the mine water liquid with small liquid as it can anti abrasive,well, SS materials is for the corrosive liquid,
for the sea water,it will be 316L SS or even better materials.
Medium:
♦ Hot and cold clean, non-flammable and non-explosive liquid without solid grain and fibre.
If for explosive liquid should choose explosion-proof motor.
♦ Mineral water, soft water, pure water, mine water,sewage,chemical liquid and other chemical mediums
♦ When the density or viscosity of liquid is larger than that of water, it is necessary to select a motor of high-power
Applications:
♦ Urban water supply and pressure boosting
♦ Industrial circulating system and processing system
♦ Water supply for boiler, condensing system, high-rise building or fire fighting system
♦ Water treatment and RO system
♦ Cooling water system
Electric motor :
TEFC motor,IEC standard,IP55/IP54/IP23,Class F/B.
Motor bearing: NSK,SKF,Common bearing also can be your choices.
50HZ or 60HZ,3-phase.
380V/415V/460V/6KV/10KV.
Parameter range :
♦ Flow Range:10~650m3/h
♦ Head range: 33~850m
Parameter data :
Model | Flow | Head | Speed | Power | Diameter mm | |
m3/h | m | r/min | KW | Inlet mm | Outlet mm | |
25-50*4 | 25 | 200 | 2950 | 30 | 80 | 80 |
46-30*3 | 46 | 90 | 2980 | 18.5 | 80 | 80 |
85-45*2 | 85 | 90 | 2950 | 37 | 100 | 100 |
155-30*6 | 155 | 180 | 1480 | 132 | 150 | 150 |
280-43*7 | 280 | 301 | 1480 | 355 | 200 | 200 |
280-65*3 | 280 | 195 | 1480 | 280 | 200 | 200 |
450-60*3 | 450 | 180 | 1480 | 355 | 250 | 250 |
600-60*4 | 600 | 240 | 1480 | 560 | 300 | 250 |
FACTORY DISPLAY:
FAQ
Q: What kind of company you are?
A: Changsha Sanchang Pump Company is a professional pump manufacturer,minaly applied
in power station,mining,industry,waste water treatment, seawater RO system etc.After
20 years of development and research,we have formed a complete system of pump design, selection, application, manufacture, marketing and maintenance.
We have passed ISO, SGS certificate. Our customers are from over 30 oversea countries. Hope to coorperate with the worldwide friends.
Q: 1. How to get our quotation in time, pls answer following questions:
1)What liquid do you transfer ? Oil, Water, Food or Corrosive Chemical liquid,with solid particle or not, and so on~
2) What's the flow or capcity (m3/h, L/m)?
3) What's the discharge head (m, feet, Mpa, bar )
If you do not have any request, we will do as our normal standard.
Good quality with competitive pirce
ISO9001: 2008, SGS certificate
Q: What are your payment terms?
A: T/T, L/C at sight, D/P, D/A or as customer required.
Q: How about the warranty?
A: One year warranty for pumps expect the easy-wearing parts, it depends on pump working condition details.
Q: What is the delivery time?
A: 7-30 days according to pump materials and quantities.
Q: Can you do OEM brand?
A: Yes, Welcome.
