G series progressive cavity pump,progressive cavity pump manufacturer,eccentric screw pump
Product Introduction
G type single screw pump for a single screw-type transport pumps, because of its excellent performance in recent years in the domestic application of rapid expansion. Its most important feature of the media flexibility and a smooth flow, pressure, pulse of small, self-absorption capacity, which is by any other species can not replace the pump can be realized liquid, gas, solid multiphase lose, applied to Chemical, pharmaceutical, electroplating, printing and dyeing, paper, electricity and other transportation industries lubrication or non-lubricating medium, corrosive media, containing a small amount of tiny solid particles of medium and low viscosity of the medium to high viscosity,
Range of Application
To handle industrial and domestic wasterwater, and muddy water containing solid particles and short fibre;To handle mediums such as oil remains in oil tankers,oil water,oil residue and etc.;
To handle thick paste ,emulsified paste,unguent cosmetics and etc.;
To handle adhesive starch ,cooking oil ,honey, pulpy sugar, mashed fruit,cream and other leftovers;
To handle paste in the industries of brewage,construction ,mining ,printing ,papermaking and etc.
Technology Parameters
Flow 0-150 m3/h
Head 60-120 m
Power 0.75-37 kw
Rotary speed 500-960 r/min
Calibre 20-135 mm
Temperature -15-200 C
Item | Mono screw pump |
Suction | Self priming |
Model | G series |
Material | Cast iron or stainless steel |
Mode | Horizontal |
Drive | Direct coupling |
Rotor | Stainless steel |
Stator | NBR, FPM, EPDM, NR |
Seal | Pack seal |
Speed | 960r/min |
Theory | Positive displacement |
Pressure | Mono(0.6Mpa) ,Double(1.2Mpa) |
Usage | High viscosity liquid |
Power | Electric |
Standard or Non | Standard |
Outlet diameter | 25-250mm |
Capacity | 0.8-150m³/h |
Head | 60-120m |
Power | 0.75-37kw |
Warranty | 12 months |
Certificate | ISO9001:2008 |
OEM | Acceptable |
Feature | Adjustable speed |
Passed solid diameter | 1.5-20mm |
Passed fiber length | 25-150mm |
*All of the enquiry will be replied within 8 working hours
*Professional pump producer, with design team.
*All of the goods are packed with standard export wooden case(non-fumigation)
*Fast delivery time: common stock model, customed type:7 working days
*Support OEM or ODM
*Fast after-service
Our company established in 1998.With 20 years developing , now our group own three factory(Pearl Pump, Modern Pump and Urumchi Pump) in Chengdu, Dongguan and Urumchi. Head office in Chengdu ,Sichuan province own 50000 s.q meters new plant, 600 professional workers, hundred million equipments and total output thousands of pumps.
To be a group, our business scope have covered all kinds of pumps, like centrifugal pump,submersible pump, vacuum pump, sewage pump, chemical pump, screw pump, diaphragm pump, fire pump, water supply equipment and so on. Also welcome custom-made and OEM service. Pearl Pump is a famous brand in China, and having 20 branches in whole country. Each city have our distributors. If you like, you can be this one in your country.
Cooperating with hundreds of middle traders before 2008,in order to service our big customers better, we built up the overseas department. Dongguan in Guangdong province is our logistics center, you can choose Guangzhou, Shenzhen, Hong Kong to ship.
Every customer mostly care products quality, our group have passed ISO9001:2008 quality control system. Double testing is our quality policy. 12 months warranty time and necessary spare parts are welcomed by our customers. For international trade, third party inspection is supported.
Q1:Are you manufacturer or trading company?
Our company are professional producer for pumps,and export pumps by ourselves.
Q2:What's your business scope?
We manufacture end/double suction centrifugal pump,vertical/horizontal multistage pump,sewage pump,vacuum pump,chemical pump, oil pump,screw pump, diaphragm pump, fire pump, constant pressure VFD water supply system and so on.
Q3:What's information for enquiry?
Basic information:flow and head.If special design,pls provide drawing.50HZ or 60HZ are both OK.
Q4:What's your payment terms?
Common payment terms:T/T 30% deposit,balance payment before shipment.
Western Union
Q5:How about warranty and after-service?
12 months warranty time after receiving days,not include quick-wear parts and default phase.We promise 24 hours action for your problem.And send parts by air or express for your fix.
