Main Equipment

1. Malt Milling System

Malt Mill: Material: carbon steel and chrome plate roller;

Double roller type malt mill machine;

Equipped with motor, belt pulley, belts, etc;

Working capacity, power and dimension is decided according to mashing system.

2.Mashing System

Mashing Tun:

Inner-Jacket (SUS304 SS)thickness: 2.5-4.0mm;

External-Jacket (SUS304 SS) thickness: 2.0-3.5mm;

Mushroom-shaped head (SUS304 SS) thickness: 2.5-4.0mm;

Insulation layer: PU/Rock Wool-thickness: 80mm;

Lauter tank equipped with plow knife;

CIP cleaning ball: Material: SUS 304; Comprehensive cleaning;

Polishing precision up to: Ra0.4m;

Outsourcing surface: Plate protection and sand polish on welding seal.

Lauter Tank

Inner-Jacket (SUS304 SS)thickness: 2.5-4.0mm;

External-Jacket (SUS304 SS) thickness: 2.0-3.5mm;

Mushroom-shaped head (SUS304 SS) thickness: 2.5-4.0mm;

Insulation layer: PU/Rock Wool-thickness: 80mm;

Lauter tank equipped with plow knife;

CIP cleaning ball: Material: SUS 304; Comprehensive cleaning;

Polishing precision up to: Ra0.4m;

Outsourcing surface: Plate protection and sand polish on welding seal.

Boiling/Whirlpool Tank:

Inner-Jacket (SUS304)thickness: 2.5-4.0mm;

External-Jacket (SUS304) thickness: 2.0-3.5mm;

Mushroom-shaped head (SUS304) thickness: 2.5-4.0mm;

Insulation layer: PU/Rock Wool-thickness: 80mm;

Heating way: Electricity heating/Steam heating/Direct fire heating;

Exhaust chimney for condensate;

CIP cleaning device: Material: SUS 304; Comprehensive cleaning;

Polishing precision up to Ra0.4m;

Outsourcing surface: Plate protection and sand polish on welding seal.

3. Fermentation System

Fermentation Tank:

Material: Inner (SUS304)thickness: 2.5-4.0mm;

External-Jacket(SUS304) thickness: 2.0-3.5mm;

Oval head cone bottom, thickness: 2.5-4.0mm.

Insulation: Polyurethane-thickness: 80mm;

Cooling way: Ice water belt cooling;

Design pressure 0.3MPa; Working pressure 0.15Mpa;

Spray ball for cleaning, comprehensive cleaning;

Foot bolt: Adjust the height of the equipment, easy to install.

Yeast Adding Tank:

Material: SUS304;

Adopts SUS 304 stainless steel fine polished process, outsider stainless steel polishing, have three connection mouths;

Adding yeast sight glasses, aseptic air mouth, and wort pipe connection mouth.

4. Cooling System

Ice Water Tank:

Inner-jacket (SUS304) thickness: 2.5-4.0mm;

External-jacket (SUS304) thickness: 2.0-3.5mm;

Insulation: Polyurethane-thickness 80 mm;

Internal and external plate protection and sand polish on welding seal;

Temperature mode: PT100 temperature probe, temperature transmitting, temperature control panel display;

Feeding method: Ethylene glycol or alcohol water fill into the tank from the top manhole. Refrigeration water fill into ice water tank from the top manhole;

Discharging method: Ethylene glycol water discharge from the ethylene glycol outlet on bottom of ice water tank. Refrigeration water discharge from the refrigeration water outlet on bottom of ice water tank.

Chiller:

Compressor is USA Copeland;

Its power and working capacity will be decided according to whole brewing system.

5. CIP System

Disinfection Tank:

Material is SUS304;

Thickness is 2mm;

Weld slinging band;

Material all adopt the international standard of 304 stainless steel, all welding are argon protection single-sided, double-sided forming.

Alkali tank:

Material is SUS304;Thickness is 2mm;

Weld slinging band;  Valves, accessories supporting;

Material all adopt the international standard of 304 stainless steel, all welding are argon protection single-sided, double-sided forming.

6. Control System

Control Cabinet:

All specification is decided according to whole brewing system.
