5L Fermenter specification sheet(Borosilicate glass)
1.1Fermenter
Description Specification container (Supply Power:220V 50Hz 16A)
Volume :5L
Design pressure:≤0.2MPa
Working pressure:≤0.05MPa
High to diameter ratio:1:2-2.5
material:316L(top cover)+ Borosilicate glass body
structure:pH, DO sensor interface standards, temperature, feed, anti-foaming, alternate port, and so on.
Stirring system.
1.Special processing in 316L stainless steel agitator shaft to achieve rigidity and impact resistance and good dynamic balance, and so on.
2.Efficient stirring an impeller type: flat twenty-four an impeller (also an anti-foam can be customized according to user requirements.)
Speed:50-800rpm,
3.Sizhe baffle
4.Fermentation special high-precision mechanical seals, to ensure pollution-free in the long fermentation
5. Fermentation tank dedicated constant torque variable speed DC motor; precision mechanical seals. The motor also can run on low-speed stability.
Electric heating temperature control system.
2.Heating power:1KW
3. Imported temperature electrode: platinum resistance
Filter system
1. Intake Filter: Sartorius, precision: 0.01μ
2. Exhaust filters: Sartorius, precision: 0.01μ
Control system
Temperature control system:
1.Display range: ℃
2. Control range: + 0.2 ℃ ± 6-65
3. Control: with hot water heating, cooling cooling water temperature cycle control cycle pumps, automatic outgassing water, overtemperature protection.high-efficiency heat exchange; intelligent PID control brings fast temperature control and energy saving.
pH control system
1. Display range:0-14ph;
2.Control range:2-12ph,±0.02pH.
3.Control:Intelligent PID automatic control for good pH control.
DO Detection Systems
1.Display range :0-200 % 1.
2. Detection: automatic
3. Control: make value-line detection
Speed Control System
1.Display range:0-1000rpm.
2.Control range:50-800rpm,±1fs %.
3. Control: intelligent PID automatic control.
Feeding system(include one peristaltic pump)
1. Control mode: manual or automatic
2. According setpoint control: Feeding
Anti-foam system
1. Control mode: manual or automatic
2. According setpoint control: Feeding
Electrode control system
Hamilton pH electrode pH electrode and cable
Hamilton did electrode as electrodes and cables
