Indonesia use shredder plastic for rasper machine

Strong Plastic Crusher Machine has wide application and is used for crushing and recycling various plastic products and old materials.

Technical Feature

New

Guangdong, China (Mainland)

Longhe

PC500A

Waste Plastic Crusher

PP/PE

Send Standard Inquiry

Add Inquiry List

$1~2

PRIMARY PARAMETERS

Condition

New

Place of Origin

Guangdong, China (Mainland)

Brand Name

Longhe

Model Number

PC500A

Use

Waste Plastic Crusher

Plastic Type

PP/PE

Shaft Design

Single

Power

15HP

Capacity

360-720kg/h

Voltage

380V

Power(W)

11000w

Dimension(L*W*H)

1110x970x1300mm

Weight

750kg

Certification

ISO9001/CE

After-sales Service Provided

Engineers available to service machinery overseas

Machine material

steel

Warranty

1 year

Used for

plastic/rubber/cardboard/fabric/foam

Blades material

spring steel, high speed steel, skd-11 etc.

Power supply

3phase, 380V, 50Hz(customized)

Sieve hole

8mm (Optional)

Rotary speed

720 R/Min

Bearing

FC214

Type

Single Shaft Shredder

Usage

Rubber Plastic Shredding

DETAIL DESCRIPTION

APPLICATION AND PROPERTIES:

1.Strong Plastic Crusher Machine has wide application and is used for crushing and recycling various plastic products and old materials.

2.The entire machine is made of steel and features stable performance and long service life,and the machine performance won't be dropped by crushing materials after long term work.

3.Adopt heavy-load bearing and oil seal with noise-isolating board,effectively prevent vibration and assure to protect the product from oil.

4.Adopt electric control safe design,the motor is installed with overload protective device and power supply interlock protective design for assuring safety when cleaning.

5.The cutter is flexible and adjustable,and can be sharpened repeatedly with ultra long service life.It is capable of easily crushing and cutting soft and hard plastic.

6.Combine separated design,the materials falling door and filter of crushing chamber are easily for disassembling and cleaning.The feet are installed with slide wheels with convenient movement.

TECHNICAL PARAMETERS:

Model	Diameter of Crushing Chamber(mm)	Crushing Ability()kg/h	Motor Power(kw)	Fixing Cutter(pcs)	Flexible Cutter(pcs)	Mechanical Dimension(mm)	Weight(kg)
PC180A	190x165	30-80	2.2	2	9	650x530x980	250
PC230A	210x235	50-110	4	2	6	750x610x1200	300
PC300A	310x245	100-250	5.5	2	9	900x760x1200	450
PC400A	410x260	200-450	7.5	2	12 18	950x860x1300	550
PC500A	510x285	360-720	11	4	15	1110x970x1450	750
PC600A	610x285	470-870	15	4	18	1110x1070x1450	950
Strong model
PC450B	440x250	200-500	11	2	21	1250x900x1450	650
PC500B	510x320	450-720	11	4	6 15	1600x960x1710	1050
PC500C	510x350	600-920	18.5	4	6 9	1300x1050x1950	1850
PC600B	610x320	500-870	15	4	6 18	1770x1200x1700	1250
PC600C	610x380	550-950	18.5 22	2	6 12	1400x1210x1950	1980
PC650C	650x435	600-1000	22	2	6 12	1500x1250x2000	2050
PC800C	810x525	800-1000	30 37.5	4	6 15	1700x1410x2250	2800
PC1000C	1020x610	1000-1300	40 55	4	9 18	2000x1980x2650	3800
PC1000CE	980x700	1000-1300	40 55	4	9 18	2150x1800x2550	3800
PC1000CA	1001x800	1300-2000	55 75	4	9 18	2150x1820x3150	4500
