China popular De-sander machine hydro cyclone for sale

PRIMARY PARAMETERS

Condition

New

Type

Gravity Separator

Production Capacity

11-220t/h

Place of Origin

Jiangxi, China (Mainland)

Brand Name

Gaoxuan Mining Machine Hydrocyclone

Model Number

FX series Mining machine Hydrocyclone

Voltage

220V/380V

Power(W)

customized

Dimension(L*W*H)

depends on the model

Weight

30-100kgs

Certification

CE,TUV,SGS,ISO9001

Warranty

1 year excluding spare parts for our Mining machine hydrocyclone

After-sales Service Provided

Engineers available to service machinery overseas

Function

Installation

Technical Guidance

Capacity

1-100 Tons / Hour

Material

Polyurethane

Application

Mining

Feeding size

0-2mm

Color

Customers' Requirements

Keywords

Mining Classifier

DETAIL DESCRIPTION

China popular De-sander machine hydro cyclone for sale

Product Description

Metal Mine Hydrocyclone, also called hydrocyclone design, is widely applied in mine-chosen technique in various metal mines.

In closed circuit grinding system, the hydrocyclone design features high classification efficiency and fine overfall fineness under high mine concentration. Classification efficiency is higher for 5-10% than common screw grader. It benefits for enhancing grader utilizing coefficient. Choose proper specification and mode concentration. This is precondition of getting the most optimized work condition.

Features of hydrocyclone

hydrocyclone design mainly shows in the following works:

1. Classification for section I closed circuit grinding

2. Classification for section II closed circuit grinding

3. Regrinding for fine mine classification

4. Mud-removing before selection and after selection

5. Dam and backfill for gangue

3.structure of hydrocyclone

Working principle of hydrocyclone

A typical hydrocyclone design consists of a conically shaped vessel, open at its apex, or underflow, joined to a cylindrical section, which has a tangential feed inlet. The top of the cylindrical section is closed with a plate through which passes an axially mounted overflow pipe. The feedis introduced under the pressure through the tangential entry which imparts swirling motion to the pulp. This generates a vortex in the cyclone. The light granules will be pulled out by a pump through the overflow pipe, while the heavy particles will be discharged with the pulp through the underflow discharge.

Technical Parameter

Model	FX125	FX150	FX250	FX300	FX350
Overflow size (mm)	15-250	25-250	25-250	25-250	25-250
Processing capacity (m2/h)	2.4-1.5	4.8-54	6.5-61.2	24-60	24-90
Permitting overflow pressure (kg/cm 2 )	0.3-3	0.3-3	0.3-3	0.3-3	0.3-3
Cyclone structural parameters	Diameter (mm)	125	150	250	300	350
Cone angle(degree)	20	20	20	20	20
Cylinder height (mm)	110	200	170	235	180
Overflow tube length (mm)	107	130	163	210	215
Feed port area (mm2)	25*10	40*10	50*20	75*20	80*35
De-silting pipeline diameter (mm)	15-30	15	35	50	25
Outline size (lengthwidthheight)	320260 648	594380 899	540475 1172	575550 1444	575690 1510
weight (kg)	80	85	210	240	280

Application of hydrocyclone

The hydrocyclone design is mainly applied to the process of second paragraph grinding, coarse or concentrate re-grinding and the closed-circuit composed by mechanical grading machine, its grading operation is according to the particle size. The device has features of simple structure, long service life, large disposal capability, small land covering and no driving power consumption. It is a high efficient grading and de-sliming equipment of fine -particle material. It is widely used in concentrator of nonferrous and ferrous, chemical, pharmaceutical, ceramics and other industries.

Accessories

polyurethane Lining inside
