Sludge Dewatering Belt Filter Press Machine with High Quality
The belt filter (sometimes called a belt press filter, or belt filter press) is an industrial machine, used for solid/liquid separation processes, particularly the dewatering of sludge in the chemical industry, mining, food processing and water treatment. The process of filtration is primarily obtained by passing a pair of filtering belts through a system of rollers. The system takes a sludge as a feed, and separates it into a filtrate and a solid cake.
Feature
1. Fully-automatic& continuous filtering
2. Lowest moisture
3. ISO9001/14001
4. Energy saving
5. Service very good
Model | DYQ-500 | DYQ-1000 | DYQ-1500 | DYQ-2000 | DYQ-2500 |
| Belt width (mm) | 500 | 1000 | 1500 | 2000 | 2500 |
| Treating capacity (m³/h) | 1~5 | 5~10 | 10~15 | 15~20 | 20~25 |
| Velocity (m/min) | 3.0~15(concentrating zone) 1.2~6.0(dewatering zone) | ||||
| Concentrating motor(kw) | 0.55 | 0.55 | 0.75 | 1.1 | 1.5 |
| Dewatering motor(kw) | 0.75 | 1.5 | 1.5 | 2.2 | 3.0 |
| Outlet height (mm) | 700 | 700 | 700 | 700 | 700 |
GOOD QUALITY IS OUR CULTURE!
GREAT SERVICE IS OUR MISSION!
Founded in 2010, Jiangsu Ponis Environmental Technologies Co., Ltd is a professional manufacturer integrated with the installation, debugging of the environmental equipment, as well as the project contracting. Covering an area of over 10,000 square meters, we have the world first-class R&D department, all kinds of monitoring equipment are available to do micro-analysis of the contaminant.
Over the last 10 years, we have gained the popularity of many customers both from home and abroad with our high quality and warm hearted service.
Export standard wooden box to avoid damage during transporation
