SELON L535-1 DISC STACK CENTRIFUGE SEPARATOR
disc stack centrifuge separator , Refrigerated Centrifuge, orange essential oils centrifuge
FEATURES | |||
Microprocessor controls rotor speed, temperature and time. | |||
Electric lock , over-speed and over-temperature protection device. | |||
RCF auto-calculating. | |||
Fast acceleration and deceleration. | |||
Multiple rotors for option. | |||
LED and large screen LCD display optional. | |||
AC converter motor with large moment and imported refrigeration compressors. | |||
SPECIFICATIONS | |||
Item No. | L535-1 | ||
Max Speed | 5350r/min | ||
Max RCF | 5030xg | ||
Max Capacity | 4x750ml | ||
Control | Microprocessor control | ||
Motor | The AC frequency conversion motor | ||
Speed Accuracy | +/-30r/min | ||
The shortest time of Acc/Dec | 100r/min-5000r/min lower than 45s/5000r/min-100r/min lower than 50s | ||
Time Range | 1s-99min 59s | ||
Temperature Range | -20 degree-40 degree | ||
Temperature Accuracy | +/- 1.5 degree | ||
Refrigeration System | No refrigeration | ||
| |||
Power Supply | Ac220V+/- 10%50/60Hz15A | ||
Noise | lower than 70dB(A) | ||
Dimension | 580x800x900(mm) | ||
Weight | 70kg | ||
ROTOR SPECIFICATIONS | |||
Rotor No. | Max RCF | ||
No. 1 angle rotor | 5030xg | ||
No. 2 swing rotor | 3300xg | ||
No. 3 swing rotor | swing rotor | 3640xg | |
adaptor | 3640xg | ||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
No. 4 | micro plate rotor | 2200xg | |
3040xg | |||
swing bucket rotor | 3040xg | ||
adaptor | 3040xg | ||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
No. 5 swing rotor | swing rotor | 3950xg | |
adaptor | 3950xg | ||
adaptor | |||
adaptor | |||
adaptor | |||
adaptor | |||
No. 6 swing rotor | 3500xg | ||
No. 7 micro plate rotor | 2200xg |
