All-round Horizontal Beads Mill is a Nano Grade liquid grinding machine for closed continuous production. Comparing with traditional grinding equipment, it uses Yttrium stabilized zirconium beads with higher specific gravity and higher hardness as grinding medium. And it shows higher grinding efficiency(2 to 3 times higher), better final fineness(nano grade), wider application (Available for middle and high viscous materials) and better wear resistance. Various of specifications are in option, easy operation and high reliability. It adopts world well-known brand Burgmann Dual-end Mechanical Seal, with self-lubricating system, more reliable and durable. The machine is also with temperature, pressure monitor and protection to ensure the quality of the finished product.
- Novel structure, high stability
Strengthened frame with reasonable structure, steady operation and easy maintenance. Besides, nicer appearance with full of modern sense. The main parts and out-sourced parts are internationally renowned brands with higher stability and longer service life.
- Easy to clean, strong durability
Unique tri-pole mechanism design makes it easy to open for cleaning and replacing grinding chambers. The grinding chamber, made of high wear-resistance alloy steel, is treated specially to realize higher wear resistance and longer service life. In addition, Burgmann Dual-end Mechanical Seal with self-lubricating system contributes directly to higher reliability and durability.
- Safe monitor, stable product
The machine is with triple cooling: internal, external, and end face, which ensures the grinding heat exchanged out in time. The water temperature, material temperature, material pressure, water pressure, air pressure and other real-time monitoring and protection system ensure proper operation of the machine.
- Full specification, can be customized
Specifications ranges from 5L to 50L, which can be customized to be Exproof type. Grinding chambers made of Polyurethane or Zirconium are in option to ensure its anti-abrasiveness and also to prevent materials from metal pollution.
Model | Power Supply |
Motor Power (kw) | Speed | Grinding Chamber (L) | Grinding Chamber Material | Capacity (L) | Medium Dia.(mm) | Zirconium Beads | Weight (kg) |
SWZX-5 | 380V 50HZ | 7.5 | 1440rpm | 5 | SS304/Alloy Steel | 50-150 | 0.5-1.8 | 95 Yttrium stabilized zirconium beads | 550 |
SWZX-15 | 380V 50HZ | 15 | 1000rpm | 15 | SS304/Alloy Steel | 100-250 | 0.5-1.8 | 95 Yttrium stabilized zirconium beads | 1200 |
SWZX-30 | 380V 50HZ | 30 | 935rpm | 30 | SS304/Alloy Steel | 150-500 | 0.5-1.8 | 95 Yttrium stabilized zirconium beads | 1800 |
SWZX-50 | 380V 50HZ | 55 | 930rpm | 50 | SS304/Alloy Steel | 200-1000 | 0.5-1.8 | 95 Yttrium stabilized zirconium beads | 2500
|
Remarks:
- If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
- The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
- Not all products are listed. For more, please contact with our sales engineer.
