maize germ separation machine
TSQX series gravity corn/maize germ extractor introduction:
TSQX series gravity germ extractor is regarded as an auxiliary in the maize processing line, germ extractor TSQX germ extractor played an important role in corn processing factory, enthanol factory, feed making factory and brewery factory, this machine has good germ extraction effect, low power, high productivity, low power consumption, good sealing effect and no flying dust.
The main model of corn/maize germ extractor machine:
Model Number | Output(k/h) | Power(kw) | Weight(kg) | Dimension(mm) |
TSQX60 | 1 | 0.55 | 100 | 1500*780*1650 |
TSQX80 | 2 | 0.75 | 150 | 1600*980*1780 |
TSQX100 | 5 | 1.1 | 200 | 600*1180*1780 |
TSQX125 | 8 | 1.1 | 250 | 1600*1400*1780 |
TSQX160 | 10 | 1.5 | 350 | 1600*1800*1780 |
Corn /MAIZE degerminator introduction:
1. Dry process to break corn
2. Cyclindrical type degerminator
3. Smooth running with low noise
As an auxiliary equipment in maize processing line, this machine is mainly used to break corn into 2-3 piece and germs will fall off the maize seeds during the breaking process. We can get a mixture of germs and granular maize at last.
Equipping with grading sieve and gravity table, we can get the pure germ with high yield. We usually use this system to get germ extra for further using like oil pressing.
FEATURES
- Scientifically reasonable design; Compact structure; easy to operate; safe and reliable;
- degerming evenly; high complete germ rate;
- The machine breaks the corn into 2-3 small particles which have a square shape and relatively are even by rigid collision and flexible kneading to ensure the integrity of germ;
- High output; Less flour; the rate of finished product can be improved greatly; it can ensure the germ get best extraction and purity;
- Applied to totally enclosed design, safe, clean, and environmental protection.
DTP series corn degerminator
model | capacity(t/h) | power(KW) | weight(Kg) | dimension(mm) |
DTP50 | 2 | 5.5 | 750 | 1350×900×1375 |
DTP75 | 5 | 18.5 | 1500 | 1750×1100×1750 |
Henan Chengli Grain & Oil Machinery Co., Ltd has decade years of researching, designing and producing experience, as a professional manufacturer specialized in producing grain processing machineries.CHENGLI is engaged specially in project design on grain processing factory of wheat flour and corn/maize flour. Our superior products are complete set of 30T-200T/D maize flour processing machine and wheat flour processing machine.
