MK Hot Sale Diatomite Pre-coating Rotary Drum Vacuum Filter

Precoat Filter is indenpently developed by our company based on absorbing foreign advanced technology, it is the high efficient and precise solid & filtrate separation equipment by adding technology to the ordinary drum filter.

Technical Feature

  • China (Mainland)
  • MecKey
  • MKPF-33
  • Engineers available to service machinery overseas
  • Precoating Vacuum Drum Filter
  • 10~60 m2
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$35~5

PRIMARY PARAMETERS

Place of Origin
China (Mainland)
Brand Name
MecKey
Model Number
MKPF-33
After-sales Service Provided
Engineers available to service machinery overseas
Item
Precoating Vacuum Drum Filter
Filter Area
10~60 m2
Sugar liquids DS Value
30% ~ 35%
Capacty
0.32~0.56m3/h
Running Vacuum Degree
0.04~0.06Mpa
Main Drive Motor Power
1.5~7.5kw
Control
Manual/Automatic/Semi-automatic
Equipment Weight
4300~19200kg
Material
Stainless Steel
More Info
Special design based on customer's requirement

DETAIL DESCRIPTION

MK Hot Sale Diatomite Pre-coating Rotary Drum Vacuum Filter

Rotary Drum Vacuum Filter

Detailed Images





Product Description

Precoat Filter is indenpently developed by our company based on absorbing foreign advanced technology, it is the high efficient and precise solid & filtrate separation equipment by adding technology to the ordinary drum filter. Diversified design and excellent manufacturing technology make it widely used in pharmaceutical,food,sugar refining, chemicals industries. It's used for the need of absorbing the filtrate and removing the filter residue.

Working Principle:



Precoat filter has almost same working principle as the ordinary drum filter, the main difference is the Precoat Filter has filter aid( diatomite, perlitle for example ) precoating before filtering. When filtering, the filter aid in the tank wil form needed precoating on the drum surface by the vacuum suction, then the slurry will be injected, by the vacuum suction the separated filrate penetrate the precoating and filter cloth, then drain out after going through the suction tube, liquide collection tube and gas-liquid separator, meanwhile the solid particles in the slurry are intercepted and scraper together with the filter aid surfice layer. When the precoating residue reached 10mm thickness, another time of precoating is needed for next working cycle.



Application Fields:



1. Various sugar liquid ( glucose, maltose, dextrin, fructose, sucrose ect ) filtering residue removal;

2. Pharmaceutical industry Taylor DX, spectinomycin fermentation liquid filtering residue removal;

3. Amino acid, enzyme preparation fermentation liquid filtering residue remval;

4. Wine and rice wine mud filtering residue removal;

5. Food, beverage and fruit juice industry filtering residue removol;

6. Chemical industry waste water filtering residue removol;

7. Carrageenan ect food additives filtering.



Product Feature:



1. Customized design to meet various customers' demands;

2. Using precoating technology, high filtrate clarity;

3. Auto scraper discharge mechanism, high filtering effect;

4. Spraying device can be added to the drum surfice to ensure better washing effect;

5. Serious process device, easy installing and using;

6. Good producing environment, easy and convenient operation.
