1. Rotary Drum Screen is offered with apertures from 0.5 mm ,1mm, 1.5mm to 3 mm;
2. Passive filtration method maximizes solids removal;
3.Large treat capacity , easy to set up with small foot print ;
4. Self-cleaning, easy to maintain, and the low running cost ;
5. Simple structure, operation simplicity, sturdiness;
7. Fine screenings.
| Material | SS304/316 |
| Certification | SGS/CE/ISO 9001 |
| Grid gap | 0.25mm~2.5mm |
| Operation | automatic |
| Processing technology | laser cutting, bending, welding |
| Capacity | 33-170m3 /h |
| Drum diameter | 610mm |
| Drum length | 610mm |
| Power | 0.55kw |
| Electrical componen | Schneider/Omron/Customize |
| Product Keywords | rotary drum bar screener,external rotary drum screener |
Drum type micro filter is one of the pre-treatment method in waste water treatment. It removes the solid content in the wastewater, meanwhile, during the time of filtering, through the rotation of drum and the recoil force of water, the screen get continuous cleaned.
