Vacuum filter
The Advantage of Vacuum Filter:
1.Mining equipment
2.High vacuum
3.Save energy
4.Compact structure,convenient maintenance
Brief Introduction of Vacuum Filter:
Zhengzhou Dahua Mining Machinery Co., Ltd. is an integrated enterprise that covers research and design, manufacture, sales, installation and after-sale service. The company mainly produces mining machine and has its own skilled technology, the Vacuum Filter is one new kind of ore processing equipment, which is used to clean the products.
Main Technical Parameter of Vacuum Filter:
GW-12 GW-20
model | Filtration area | Barrel | Filters form | Capacity (flotation) (t / h) | Shell speed (r / min) | Matching Motor | External dimensions (mm) | Weight (t) | ||
Diameter (mm) | Length (mm) | Model | Power | |||||||
GN-8 | 8 | 2956 | 1020 | in | 2.4-5 | 0.34-1.43 | Y112M-6 | 2.2 | 3200×3176×3367 | 6.94 |
GN-12 | 12 | 2956 | 1370 | in | 3.5-7 | 0.34-1.43 | Y112M-6 | 2.2 | 3200×3176×3367 | 7.0 |
GN-20 | 20 | 3670 | 1920 | in | 6-12 | 0.12-2.18 | Y132M2-6 | 5.5 | 5120×3900×4050 | 12.7 |
GW-5 | 5 | 1750 | 970 | out | 0.5-1.5 | 0.13-0.49 | Y90S-4 | 1.1 | 2975×2570×2092 | 3.9 |
GW-10 | 10 | 2000 | 1880 | out | 1.5-5.5 | 0.18-0.37 | Y112M-6 | 2.2 | 4340×3400×2240 | 5 |
12 | 2000 | 2000 | out | 4.8 | 0.10-0.60 | Y112M-6 | 2.2 | 4110×2820×2450 | 5.6 | |
20 | 2000 | 2650 | out | 2-8 | 0.14-0.5 | JDO-42-8/4 | 2.5/4 | 4480×4085×2890 | 10.6 |
