Solid-liquid separator, sludge dewatering press filter

The stir turns into variable -frequency reciprocating hard stir devices that may set different stirring rates as per different materials via frequency control, which can intervene the sedimentation of ore pulp particals without dead angle to ensure the ef

Technical Feature

  • New
  • Automatic
  • High Efficiency
  • Shandong, China (Mainland)
  • XINGHUA
  • PYNTK-96
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$300~600

PRIMARY PARAMETERS

Condition
New
Automatic Grade
Automatic
Production Capacity
High Efficiency
Place of Origin
Shandong, China (Mainland)
Brand Name
XINGHUA
Model Number
PYNTK-96
Voltage
380v/220v
Power(W)
59.5 kw
Weight
83000kg
Dimension(L*W*H)
11.65*5.3*a m
Certification
ISO9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Name
Filter press
Filter area
96 u33a1
Keywords
Filter Machine
Description
Solid-liquid Separation Machine

DETAIL DESCRIPTION

Product Description
Sludge dewatering press filter,  pressure filter

Performance features:
1.The stir turns into variable -frequency reciprocating hard stir devices that may set different stirring rates as per different materials via frequency control, which can intervene the sedimentation of ore pulp particals without dead angle to ensure the effects of stir and filtration.
2.The discharge device is equipped with new discharge gate limit detection device which could lengthen the service life of proximity switch to ensure reliable operation of equipment.
3.Allocate dedicated belt conveyor to undertake the collection and transportation of materials within the warehouse, and take anti-abrasive measures for feeding pipeline, feed-back pipeline and flow passage components to ensure the service life of the complete machine.
4.Allccate new monofilament and multifilament filter mediums, with long service life and fine technical indicators.
5.The new electronic control system saves installation time of wiring, decreases failure rate, and reduces cable amount of more than two thirds, which has been solved the problem of signal interference to analog signals of pressure transmitter and level transmitter, etc.

Detailed Images
Model & specification
PYNTK-96
Filter area (m²)
96
Filter disc diameter (m)
3
Quantity of filter discs
8
Rotating speed of filter disc (r/min)
0.4-1.5
Water content in filter cake (%)
8-11
Working pressure (MPa)
0.25-0.5
Packing & Delivery

According to relevant requirements.
