Alumina LPG centrifugal spray dryer/spray drying machine/spray drying equipment for sale

What the most widely used in liquid process shaping and drying industry is spray dryering.

Technical Feature

  • New
  • Spray Drying Equipment
  • Jiangsu, China (Mainland)
  • SM
  • LPG-100
  • 380V
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$10~15

PRIMARY PARAMETERS

Condition
New
Type
Spray Drying Equipment
Place of Origin
Jiangsu, China (Mainland)
Brand Name
SM
Model Number
LPG-100
Voltage
380V
Power(W)
81
Dimension(L*W*H)
4.6*4.2*6
Weight
1000kg
Certification
ISO9001
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Name
LPG size centrifuge spray dryer machine
Model of Druing Machine
LPG spray dryer
Certificate
ISO9001
Service
engineers available to service machinery overseas
Heating Source
electrical, oil, coal, steam
Steel Material
stainless steel
Overall View
silver, blue, green, etc.
Installation
professional nstallation instructions by Shengman
Electricity
220V/240V/380V, 50Hz/60Hz, 3 phases
Power
depends on the specific model

DETAIL DESCRIPTION


Item Informations

Description of spray dryer:
What the most widely used in liquid process shaping and drying industry is spray dryering. Applies to most from solution, emulsion, suspending liquid and paste liquid raw materials generated in the powder, granular solid products. Therefore, when the particle size distribution of the finished product, residual moisture content, bulk density and particle shape must meet the precision standard, the spray drying is an ideal process. The classic drying raw material of spray dryer is milk powder, coffee, juice, vegetable extract, pumpkin, gelatin, etc.





Principle:
After filtering and heating, air into the dryer on top of the air distributor, hot air spiraling evenly into the drying chamber. Material liquid via high-speed centrifugal atomizer, on top of the tower body (rotating) into a very fine mist spray liquid bead, contact with the hot air and flow, in a very short period of time can be dry for the finished product. Finished products continuously by drying the bottom and the output of the cyclone separator, exhaust fan emptying.





Features:
(1) Fast drying speed, material liquid after atomization, significantly increased surface area, in the hot air flow, instantaneous evaporation can be 95%-98% moisture, to complete the drying time only a few seconds, and especially suitable for drying of thermal sensitive material.
(2) Products with good uniformity, fluidity and solubility, the product high purity, good quality.
(3) Production process is simple, convenient operation and control. Special material for 40-60% moisture content (90%) of the liquid to a dry powder products, dried without crushing and screening, reduce the production process, improve product purity.

(4) To the product particle size, bulk density, moisture, within a certain range can be adjusted by changing the operating conditions, control and management is very convenient.





Our company, Jiangsu Shengman Drying Equipment Engineering Co., Ltd is one of the leading production enterprises in the drying equipment engineering field in China. We have more than 180 employees and hold several workshops, like the independent office building, storehouse, testing laboratory workshop, production workshops and electrical workshop.



At present, we can supply kinds of drying, mixing and grinding equipment, like KJG series hollow blade dryer, PLG series continual plate dryer, XSG series spin flash dryer, ZKG series vacuum paddle dryer, DW series mesh belt dryer, spray dryer, SHK series mixer, 30B grinder, coal-fired hot air furnace and so on. Believe that we can provide you with services and equipment as you prefer more professional and wonderful.





Q: How can I visit your factory?
A: Our company is in Changzhou city, and it is very near Shanghai city. It takes about 1 hour to get to Changchou. Or we can even visit you in Shnghai.



Q: What’s the quality of your products?
A: Our products come with best quality, and passed CE certification. And exported to lots countries around the world, such as Australia, Malaysia, Vietnam, Philippines, Korea, Brazil, Argentina, Russia, South Africa, etc. You can rest assured with the quality absolutely.



Q: What to do if the machine has a problem?
A: 24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.



Q: How long is the warranty of your equipment?
A: One year / 12 months.



Q: What is your payment term?
A: Our usual payment term is T/T. 30% T/T in advance, another 70% T/T before shipment. Other ways can also be received after we discussion and agreement.



Q: Does your price include freight?
A: The price we offer usuallly is FOB Shanghai price. If you request CIF, please give us your delivery port, and even can offer the EXW price (machine cost) for you.









Sale service:

1. Ensure product with high quality and pre-commissioning before delivery.
2. Delivery on time.
3. Provide full set of documents as customer’s requirements.



After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the drying equipment.
3. Train the first-line operators.
4. Examine the drying equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship with all my clients.



Service commitment:
1. We provide clients one-year warranty to make sure the machine work well.
2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.
3. We send every client a preferential and reasonable quotation.





In order to quote you the right drying machine machine with best price, we would like to get the following information:



1. Name & state of drying raw material

2. Primary moisture & Final moisture

3. Max drying temperature

4. Finished products' capacity per hour

5. Heating source ( like Natural gas, electricity, fuel oil or steam)

6. Electricity information in the using field

7. Steel material of drying machine

8. Other special drying requirements
