Crystallization tank(cylinder tank,crystallization pot)
Fermentation Tank(seed tank, crystalizing tank)is wideky applied in pharmacy, fine chemical engineering and biological engineering in dustries. The tank body has inerlayer and heat-insulating layer(for heating, cooling of heat insulating).The tank body, upper and lower closure heads(or tape)all adopt spinning R-angle processing, The internal wall of the tank ha got mirror polishing with finish Ra≤0.4m. It has no sanitary dead corner and its wholly-enclosed design ensures that material are always.
Mixed and ferment at non-pollution state, It is equipped with devices including air respirator, cleaning ball,sanitation inlet, viewing mirrir,and viewing lamp, The fermentation process of Pharmacy, fine chemical engineering and biological products are aseptic and untainted, Fermentation tank adopts aseptic system which helps aviod microorganism pollution in the air and greatly extends qulity warranty period and purity of the products. We specially designed and installed aseptic resoiratry air hole or aseptic normal-pressure fermentation system,which can finish circulating heat-up and cooling through medium heat-up and cooling, The parts that contact materials are all made of stainless steel SUS304 or SUS316L . Heat preservation adopts polyurethane blister or pearl cotton. External surface adopts sand grinding surface polishing treatment. All is in accordance with GMP standard.
Volume has different specifications ranging from 100-20000L.
Type specifications | 100L | 200L | 500L | 1000L | 2000L | 5000L | 10000L | 20000L |
mmDiameter(mm) | 400 | 500 | 700 | 900 | 1200 | 1500 | 1800 | 2300 |
mmHeight(mm) | 2000 | 2300 | 2650 | 2900 | 3800 | 4480 | 5250 | 6550 |
MpaPressure in the tank(Mpa) |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
MpaJacket pressure(Mpa) |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
Quantity of mixer blade | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 4 |
r/min Rotate speed(r/m) | 80 | |||||||
KwMotor power(kw) | 0.55 | 0.75 | 1.1 | 1.5 | 3 | 5.5 | 7.5 | 7.5 |
Cooling modes |
jacket |
Tube |
