| Model | ST-R10 |
| Rotary Bottle | 10L,diameter of flange opening:Φ95mm |
| Collecting bottle | 5L |
| Speed-regulation of main machine | Digital display, variable frequency, stepless Speed-regulation |
| Rotaring motor (W) | DC motor, power: 90W |
| Condensing tube | Standing, main + auxiliary cooling and highly efficient 3 circulating coldtrap |
| Heating boiler | Stainless water bath |
| Temperature control | Digital display, temperature control,0~99°C |
| Achievable vacuum | 399.9Pa (below 3mmHg) |
| Evaporating capability | Water≥3.2L/h Alcohol≥6.5L/h |
| Elevating function | Manual elevation |
| Elevating stroke | 0 -160mm |
| Rated power supply | 220V/50Hz |
| Power of power supply | 4.8KW |
| Dimensions of main machine (mm) | 990W*550D*1655H |
| Dimensions of explosion-proof electric box (mm) | 500W*455D*985H |
| Weight of main machine (kg) | 85 |
| Weight of explosion-proof electric box (kg) | 58 |
- p
- Features of multiple effect evaporator:
- 1. Teflon (PTFE) and fluorine rubber dual rotating seal, patented technology to ensure high vacuum.
- 2. the introduction of foreign advanced frequency control system, temperature control system, accurate and reliable
- 3. a vacuum switching valve, without affecting the system vacuum distillation of the situation and the solution can be continuously collected.
- 4. water bath electric lift and manual lift support, easy to use.
- 5. PTFE discharge valve, corrosion resistance, pollution-free.
1. Customers encounter problems when using our products , pls contact us by telephone or email, we will be ready to provide consulting, maintenance and other services immediately
2. One year warranty service after the product was sold
3.In the warranty period, users operate according to instruction but meet problems, our company will maintain free of charge.
1. Where is your factory located? How can I visit there?
Our factory is located in Zhengzhou City, Henan Province, China, near Zhengzhou.You can fly to Xinzheng airport ,you can take tax or metro to Zhengzhou directly. All our clients, from home or abroad, are warmly welcome to visit us !
2.What's the minimum order quantity?
One set at present.
3.What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C.The exactly term with be discussed during the deal.
4.How will you delivery these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and sea.
5.Can you provide overseas services if there are problems with machines ?
Yes, we can provid overseas services.
Welcome to our company!
The full name of our company is Henan Sinobrother Technology Co., Ltd Our company has been developing for ten years.
We mainly specialized in different kinds of Lab Instruments, including Evaporators, Reactors, Freeze Dryer, Microscope etc., and Biochemical Incubator, and Freeze Dryer for commercial use and lab use.
We have 40 salesmen working on the front line to provide high quality products & full services for the clients!
