Multiple Effect Evaporator
Characteristics of multiple effect evaporator:
1. Motorized lift
2. Water or oil bath
3. Build in vacuum controller
4. With digital display and control
5. With vertical or diagonal condenser
6. Variable inclination angle of evaporating flask
7. Fitted and designed for controlling and communication by PC
Technical Data of multiple effect evaporator:
Model | RE-1002 |
Rotary flask(L) | 10 |
Collection flask(L) | 5 |
Motor power(W) | 120 |
Rotating speed (rpm) | 3~110 |
Water bath power(kw) | 3 |
Power supply | 220V/50HZ |
Bath temp control range(°C) | RT-99 |
Sealing | PTFE sealing |
Vacuum degree | <133pa |
Model | RE-205 | RE-52AA | RE-301 | RE-501 | RE-1002 | RE-2002 | RE-5002 |
Rotary flask(L) | 0.5-2 | 3 | 5 | 10 | 20 | 50 | |
Collection flask(L) | 1 | 2 | 3 | 5 | 10 | 20 | |
Motor power(W) | 40 | 60 | 120 | 180 | |||
Rotating speed (rpm) | 3~120 | 3~110 | 3~90 | ||||
Water bath power(kw) | 1.5 | 2 | 3 | 5 | |||
Power supply | 220V/50HZ | ||||||
Bath temp control range(°C) | RT-199 | RT-99 | |||||
Sealing | PTFE sealing | ||||||
Vacuum degree | <399.9pa | <133pa |
Pictures of multiple effect evaporator:
Matched Equipments of multiple effect evaporator:
The large capacity ,evaporation area is large,the reduced pressure in water ,the side spin edge heat ,the solution,and can be used for high efficiency diffusion evaporation biological ,pharmaceutical ,chemical , food and other ares of test ,test and production .The product can be and circulating water type multi-purpose vacuum pump ,the diaphragm vacuum pump ,low temperature cycle (vacuum) pump ,circulation cooler ,constant temperature cycle device ,low temperature cooling fluid circulation pump and other supporting composition device.
Our company is specializing in lab instruments for more than 10 years, with rich experiences. Our main products are Glass reactors, Rotary evaporators, and so on. If you have any needs of lab instruments, please feel free to email us. Thanks!
Our company guarantees after-sale service of one year. In this year, users operate the instruments according to instructions and come across problems, free services and repairs from our company. After this year, we can also provide repairs, but the bills are at your cost.
