M5 JAC1000 series pneumatic air source treatment system

               JAC1000 series air source treatment  JAC 1000-5000 Series Air Filter Combination(F.R.L Combination)Model JAC 1000JAC 2000JAC 2500JAC 3000JAC 4000JAC 5000Guaranteed.pressure reistance1.5MPaMax.Working Pressure1.0MPaWorking Tem

Technical Feature

  • Source Treatment Unit
  • Zhejiang, China (Mainland)
  • JAC
  • JXPC
  • M5 JAC1000 series pneumatic air source treatment system
  • Aluminum Alloy
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Type
Source Treatment Unit
Place of Origin
Zhejiang, China (Mainland)
Model Number
JAC
Brand Name
JXPC
Product name
M5 JAC1000 series pneumatic air source treatment system
Material
Aluminum Alloy
Port size
M5
Color
Silvery
Body Material
Die-casting Aluminum Alloy
Fluid
Air
Application
Automatic Control
Working medium
Air Water Oil Gas
Certificate
ISO9001

DETAIL DESCRIPTION

               JAC1000 series air source treatment

JAC 1000-5000 Series Air Filter Combination(F.R.L Combination)
Model JAC 1000JAC 2000JAC 2500JAC 3000JAC 4000JAC 5000
Guaranteed.pressure reistance1.5MPa
Max.Working Pressure1.0MPa
Working Temperature 5~60℃
Filter precision25(5um is optional)
Recommended OilTurbine No.1 oil ISOVG32
Bowl materialPolycarbonate
Bowl guardNoneAvailable
Pressure Adjusting Range0.05~0.7MPa0.05~0.85MPa
Drain FunctionDifferential Drain    Automatic Drain
Valve typeWith overflow
JAC 1000-5000 Series Air Filter Combination(F.R.L Combination)
Model JAC 1000JAC 2000JAC 2500JAC 3000JAC 4000JAC 5000
Guaranteed.pressure reistance1.5MPa
Max.Working Pressure1.0MPa
Working Temperature 5~60℃
Filter precision25(5um is optional)
Recommended OilTurbine No.1 oil ISOVG32
Bowl materialPolycarbonate
Bowl guardNoneAvailable
Pressure Adjusting Range0.05~0.7MPa0.05~0.85MPa
Drain FunctionDifferential Drain    Automatic Drain
Valve typeWith overflow
