automatic gate access control system for apartment

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin

Guangdong, China (Mainland)

Brand Name

RS Security

Model Number

RS 716

Application

Access Control System

Sensing Method

Slot Reader

Movement

Single Core

Type

Swing Gate

Control Mode

Automatic

Communication Interface

TCP/IP

Gate open&close time

0.6S

Get to work state after breakdown

Reset time after breakdown

10s

DETAIL DESCRIPTION

Product Description:

Low Price Automatic High Security Swing Barrier for Super Market Access Control

Quick Details

1	Place of Origin	Guangdong, China(Mainland)
2	Brand Name	RS Security
3	Model Number	RS718-15
4	Material	304 stainless steel
5	Thickness of steel	1.5mm
6	Dimension	L1030x H890mm
7	Arm length	≤1500mm
8	Power supply	AC 220V
9	Transit speed	50 persons/min
10	Operating environment	indoor/outdoor
11	Operating temperature	-30~60
12	Operating humidity	lower than 95%

Tripod Turnstiles systems provide effective means for pedestrian flow control at entrances of production facilities, administrative buildings, company offices, schools, university campuses, stadiums, leisure and fitness facilities, amusement parks and zoos, shopping outlets.

Specification:

Housing material:304 stainless steel
Dimensions:L1000 x W280 x H980mm
Arm length: 550mm
Voltage:AC220V ± 10%
Frenquency:50Hz
MCBF: 5 million cycles
Transit speed:35 persons/min
Operating environment: Indoor/outdoor (Shelter)
Operating temperature: -30°C ~ 60°C
Operating humidity: ≤95% no condensation

Features

1. Incorporating advanced hydraulic kinetic buffering technology to ensure fast and smooth operation.
2. Equipped with standard input/output signal interface, can be integrated with all types of access control panel, offering complete entrance control solutions.
3. Equipped with LED directional indication / status lights.
4. Equipped with mechanical Fail-Safe mode. In the case of power failure, the Tripod arms can be triggered to drop automatically to ensure unblocked access.
5.The positive action lock also helps in preventing two passage at one time.
6. Anti-Illegal Entry with forced rotation feature which can withstand force of up to 80kg.
7. Unique tripod design ensures safe and reliable operation. Highly durable design ensures life span more than 5 million cycles.
8. When the turnstile arms have rotated for more than 60 degrees, the mechanical override will be activated automatically to prevent tailgating.
9. The emergency button which can ensure unblocked access is available.

Packaging & DeliveryPackaging DetailsDelivery Detail

Wooden well protection package

3-7 days after receipt of payment

Fast wayCheap way:

By express,such as: DHL, Fedex, UPS, TNT, EMS...take about 3~7days.

Sea shipment.

Our Service

1. 3 years Standard Warranty, excellent after-sales service, online lifelong technical support
2. 24h*7d at your service to give you the best support;
3. Detailed installation video and wiring diagram to make everything easy
Company information:
RS Security Co., Ltd located in Guangdong, China, is specialized in manufacture and marketing of security products. Now is a leading supplier of access controller, time attendance, electromagnetic lock, electric lock, tripod turnstile, flap barrier, swing barrier gate, and other parts of access control system such as access control panel, door closer, card reader, power supply, exit button. Besides, we also try to enlarge our scope in security area, like video phone, intercom system, guard tour patrol system. Most of our products have been certified by CE, FCC and ROHS standards. At present, we export products with high quality and competitive price to all over the world. RS Security is committed to continually providing customers with the solutions for their security requirement. Please feel free to contact us. We glow with customers!

Functions

1, Malfunction self-check and alarm reminder, ease of maitenance and use
2, Running method can be set through small buttons on the control panel
3, How arm reacts in emergency
4, How arm reacts when power on
5, Self-reset. pass right will be cancelled if people do not go through within a set time, the default time is 10s ( 0-60 adjustable)
6, Compatible for access control system, consumption system, E-ticekt system, biometric system, ESD system and so on
7, Unique positioning, self reset, one arm always in the horizontal level
8, LED lamp indicator
9, When open signal is given, arm rotate to a certain degree
10, How arm reacts when people passing
11, One direction or bi-direction flow control
12, Work directly with PC for remote control and management
13,LED counter Display
14,Bi-direction Anti reverse rotation
