Widely Used Control Cabinet, Electric Box for Deep Well Pump

Widely Used Control Cabinet, Electric Box for Deep Well Pump Product Description ModelCapacitorMain FeaturesC1-S120uf1. Over Load Protection2. Motor Stalled Protection3. Dry Run Protection With Sensor Free4. Under / Over Voltage Protection5. Memor

Technical Feature

Guangdong, China (Mainland)

Liyuan

C1-S2

IP54

Control Box

Standard

Send Project Inquiry

Add Inquiry List

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin

Guangdong, China (Mainland)

Brand Name

Liyuan

Model Number

C1-S2

Protection Level

IP54

Type

Control Box

External Size

Standard

Name

Widely Used Control Cabinet, Electric Box for Deep Well Pump

Usage

For Submersible Pump

Hull Material

Stainless Steel

IP Protection Grade

IP54

Overload Protection

Display

LCD

Capacitor

20-60uf

Frequency

50/60Hz

Running

Auto / Manual

Calibration

by Push Button

DETAIL DESCRIPTION

Widely Used Control Cabinet, Electric Box for Deep Well Pump

Product Description

Model	Capacitor	Main Features
C1-S1	20uf	1. Over Load Protection 2. Motor Stalled Protection 3. Dry Run Protection With Sensor Free 4. Under / Over Voltage Protection 5. Memory Function When Power Off & Recovery 6. LCD Screen Displays Pump Running Information 7. Push Button Calibration 8. Complete with Capacitor 9. IP 54 Protection Grade
25uf
30uf
40uf
45uf
60uf
C3-SP1		Main Features
1.Built in Function Switch For Water Transfer, Booster and Sewage Lifting (Drainage) 2. Auto / Manual 3. Over Load Protection 4. Motor Stalled Protection 5. Under / Over Voltage Protection 6.Open Phase Protection 7. Dry Run Protection With Sensor Free 8. Available Terminals For Level Sensor, Float Switch, Pressure Switch Wiring 9.Memory Function When Power Off & Recovery 10. LCD Screen Displays Pump Running Information 11.Push Button Calibration
