electric control distribution outdoor electrical cabinet waterproof enclosure cabinet ip67

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin

Zhejiang, China (Mainland)

Brand Name

XJELE

Model Number

XJBS-A 202015

Protection Level

IP65

Type

Distribution Box

External Size

200x200x150mm

Material

Steel sheet

Certificate

Color

RAL 7035

Thickness

0.8-1.5mm

Surface treatment

Powder coating spray

Lock

zinc alloy

Customized

Protection degree

IP65

Against mechanical impacts

IK10

DETAIL DESCRIPTION

Product Description

XJBS-A is made from sheet steel, designed to be assembled with various electrical componets according to different control function requirement.

ctric control distribution outdoor electrical cabinet waterproof enclosure cabinet ip67

Body Material	Steel sheet	Mounting Plate Material	steel sheet/ galvanized steel
Body Color	RAL7035	Mounting Plate Color	RAL 2000/Silvery white
Body Thickness	1mm/1.2mm/1.5mm	Mounting Plate Thickness	1.5mm /2mm
Body Surface Finished	powder coating textured finish	Mounting Plate Surface Fished	powder coating flat finish
Protection Degree	IP 65	Against Mechanical Impacts	IK 10

Feature:

1.Dust and waterproof : Using PU foam sealing gasket insdie to prevent dust and water.
2.Door opening angle: 120 by plugging hingers.

3. hanging holes in the back of the enclosure, installed by the wall mounting brackets wich need ordered separately.
4.The eage of The mounting plate is bend, strengthens the strength.

5.Reserved hole for exchange between left open door and right open door.

6.The four protrusion punching holes used to install the mounting plate on the floor are designed to increase the impact resistance of the shell.

7.Higher than 600MM, the door panel will use reinforcing porfile to increase the compression resistanceand and strength of the door.

Specification

Mode	Size H(mm)W(mm)D(mm)	Gland Plate Size	Mode	Size H(mm)W(mm)D(mm)	Gland Plate Size
XJBS-A 2020/15	200	200	150	A	XJBS-A 6040/20	600	400	200	C
XJBS-A 2520/15	250	200	150	A	XJBS-A6040/25	600	400	250	C
XJBS-A 3020/15	300	200	150	A	XJBS-A6040/30	600	400	300	C
XJBS-A 3025/20	300	250	200	A	XJBS-A6050/20	600	500	200	D
XJBS-A 3030/15	300	300	150	B	XJBS-A 6050/30	600	500	300	D
XJBS-A 3030/20	300	300	200	B	XJBS-A 7050/20	700	500	200	D
XJBS-A 4030/15	400	300	150	B	XJBS-A7050/30	700	500	300	D
XJBS-A 4030/20	400	300	200	B	XJBS-A 7060/20	700	600	200	D
XJBS-A 4030/25	400	300	250	B	XJBS-A 7060/25	700	600	250	D
XJBS-A 4030/30	400	300	300	B	XJBS-A 8060/25	800	600	250	D
XJBS-A 4040/15	400	400	150	C	XJBS-A 8060/30	800	600	300	D
XJBS-A 4040/20	400	400	200	C	XJBS-A 8080/25	800	800	250	F
XJBS-A 4040/25	400	400	250	C	XJBS-A 8080/30	800	800	300	F
XJBS-A 4040/30	400	400	300	C	XJBS-10060/20	1000	600	200	D
XJBS-A 5030/20	500	300	200	B	XJBS-10060/25	1000	600	250	D
XJBS-A 5030/25	500	300	250	B	XJBS-10060/30	1000	600	300	D
XJBS-A 5030/30	500	300	300	C	XJBS-10070/20	1000	700	200	D
XJBS-A 5040/15	500	400	150	C	XJBS-10070/25	1000	700	250	D
XJBS-A 5040/20	500	400	200	C	XJBS-10070/30	1000	700	300	D
XJBS-A 5040/25	500	400	250	C	XJBS-10080/30	1000	800	300	F
XJBS-A 5040/30	500	400	300	C	XJBS-12060/25	1200	600	250	D

Components

Our Company

Wide Product Range to Choose from
Wenzhou Xujie Electric Co. Ltd is located in Yueqing China. We are a professional committed to production, research and development, and sale of wall-mounted sheet steel electric enclosures, non-standard irons, stainless steel, aluminum alloy, plastic electrical, electronic cabinets and boxes， terminal.

Exporting Products Worldwide
With “The best for you” motto, we combined innovation and high quality. We want to be your best choice for distribution box and cabinet. Our products are sold widely to more than 30 countries and regions.
