Plastic pvc pipe machine / PVC conduit pipe production line / PVC plastic pipe extrusion line

Single screw extruders or conical twin-screw extruders are used as main machines of plastic pvc pipe machine.

Technical Feature

  • New
  • Pipe Production Line
  • PVC
  • Energy Supply Pipe
  • 0.1-12m/min
  • Jiangsu, China (Mainland)
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Condition
New
Type
Pipe Production Line
Pipe Material
PVC
Application
Energy Supply Pipe
Production Capacity
0.1-12m/min
Place of Origin
Jiangsu, China (Mainland)
Brand Name
MS
Model Number
MSG
Voltage
220V/380V/440V
Power(W)
as per actual need
Dimension(L*W*H)
as per the configuration
Weight
as per the configuration
Certification
ISO9001
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Color
custom made
Screw
twin screw
Main electric componets
Siemens
Inverter
ABB
Main motor
Siemens
Temperature talbe
Omron
Technical support
lifetime
Test
the plastic pvc pipe machine will be tested before shipment

DETAIL DESCRIPTION

Plastic pvc pipe machine / PVC conduit pipe production line / PVC plastic pipe extrusion line

The composed of plastic pvc pipe machine:

Single screw extruders or conical twin-screw extruders are used as main machines of plastic pvc pipe machine. Then auxiliary equipped with mould, calibration unit, haul-off unit, cutting unit and stacker, mixer and so on.



 Some main parameter of plastic pvc pipe machine:

Specifications / Model

MSSZ51

MSSZ55

MSSZ65

MSSZ80

MSSZ92

Screw-stem diameter(mm)

51/105

55/110

65/132

80/156

92/185

Screw-stem rotation rate(r/min)

1-45.5

1-40

1-38

1-36.9

1-34.7

Screw-stem effective length (mm)

1050

1200

1440

1800

2500

Main motor power (kw)

15

22

37

55

110

Heating power(kW)

11.5

13

20

31

88

Hourly output(kg/h)

80

150

250

360

1000

Equipment center height(mm)

1000

1000

1000

1100

1200

Net weight(kg)

3000

3500

4000

5000

5500

Dimensions(L×W×H)mm

3360×1290
×2100

3620×1350
×2200

4235×1520
×2450

4750×1550
×2460

6000×1600
×2500





Now plastic pvc pipe machine is one of our leading products.  We've obtained rich experience in design and manufacture of the whole extrusion lines.

Pls feel free to contact us if you have any questions about plastic pvc pipe machine.



 Our Service:

 1) We recommend of machine and auxiliary equipment and relevant budgeting, human resources allocation and budgeting.

 2) We provide you with free training so that you can use and maintain the machine independently.

 3)We will answer customer's questions on technology in time. If needed, we will offer on-site guidance and assistance.
