Warranty 15 years Anticorrosion corrugated FRP panels

Chemical plant, The chemical fertilizer plant etc the plant of acid-base corrosion gas.

Technical Feature

  • Hebei, China (Mainland)
  • AIDUOMEITE
  • YX51-380-760,YX60-470 etc.
  • Pickling shop,MSG factory,Chemical plant etc
  • Anti-aging Film
  • FRP Continuous Production Line
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin
Hebei, China (Mainland)
Brand Name
AIDUOMEITE
Model Number
YX51-380-760,YX60-470 etc.
Application
Pickling shop,MSG factory,Chemical plant etc
Surface Treatment
Anti-aging Film
Technique
FRP Continuous Production Line
Dimensions
Customizable
Material
Vinyl anti-corrosion resin, fiberglass,film
Color
customised
Standard Thickness
1.5mm,2.0mm,2.5mm,3.0mm
Width
1-1.5m
The Content Of Glass
u226530%
Applicable Temperature
-50 u2103 ~ +130 u2103
Anti-UV
100%
oxyen index
u226530
Tensile strength
110MPa
Bending strength
195MPa

DETAIL DESCRIPTION



Warranty 15 years Anticorrosion corrugated FRP panels

Product Description

Anti-Corrosion corrugated FRP( Fibreglass reinforced sheet) for panels





Raw material

Film

Melinex 301 Anti-aging film

Resin

Vinyl anti-corrosion resin

Fiber

Owens Corning, Shandong TAISHAN(content ≥30%)

Specifications

Standard thickness

2.0mm

2.5mm

3.0mm

 Performance

index

Standard color

Blue, white(other color)

   Weathering temperature

-50℃ ~130℃

Anti-UV

100%

oxyen index

≥30

Physical performance index

Tensile strength

110MPa

Bending strength

195MPa

Barcol hardness

≥50

Thermal expansion coefficient

1.5 ˜3.2x10ˆ(-5)m/m/℃

Impact strength

90MPa

Thermal conductivity

0.158W/M.K

Density

1.41g/m²

Anti Acid-base performance index

NaOH

20%

HCL

30%

H2SO4

20%

HNO3

20%

Shelf Life

25years

Application

Pickling shop, Monosodium glutamate factory( MSG factory),Chemical plant, The chemical fertilizer plant etc the plant of acid-base corrosion gas.



Company Information



Handan Donghong FRP And Colour Steel Manufacturing Co., Ltd. ,established in 2008,which is located on the known steel city---Handan.



Donghong has been committed to the design of  FRP, Sandwich panels/Clean Room Panels, Nano insulation anti-corrosion plate

,PPGI, DUST SCREEN,C/Z section steel and other building system,and is the largest enterprise which engaged in the design,development,production,sales,installation.At present,we have more than twenty product lines,there include automatic mechanical technology FRP product line,FRP coating production line of advanced technology, glass fiber reinforced plastic tile production line,color steel pressure plate product line,C/Z section steel product line  etc.It already formed the complete system in the FRP and Puruification Board. In the fierce market competion,Donghong got the approval of customers by continuously insisted the customer first,quality first,faith based on the business philosophy. The products sold at home and abroad.





In future,we will also satisfy customers demand with best quality and sincere service with the principle of pragmatic,enterprising and innovative.We sincerely hope new and old customers with together to create the brilliant tomorrow.

Production workshop


Packaging & Shipping

The packing is with woven bag.


Product feature

1. Anti- corrosion and no pollution

2. Anti-fouling and moth resistant

3. Heat and frost resistant

4. Light weight and high strength

5. Small frictional resistance and high transport capacity

6. Good Thermal Insulation

7. Good wear resistance

8. Low maintenance cost

9. Good ability for design
10. Long service period and good comprehensive benefit
