Product Introduction
| Advantage: | |
| 1. Lithium batteries ,light weight,One person alone can handle | |
| 2. Easy to learn | |
| 3. Germany import brushless motor,maintenance-free | |
| 4. Improve the efficiency of pesticide ≥90% | |
| 5. save water 90% ,save pesticide ≥40% | |
| 6. Operation area of up to 4 hectares per hour | |
| 7. To adapt to any working environment(Paddy fields, hills, mountains, deep shrub) | |
| 8. wide-range use(Pesticide, fertilizer, herbicide, breeding pollination) | |
| 9.Down wind field is big, drug can effectively penetrate and cover crops root | |
| 10.A body to safeguard(Remote operation from the hurt) | |
| 11.No mechanical damage to crops. |
Main Parameter
| parameter | |
| size of plane | 1760*580*750mm |
| weight: | 11kg |
| maximum take-off weight | 32.5kg |
| capacity of pesticide tank: | 17L |
| The plane body | Germany import brushless motor(5500W),Imported large torsion server,Germany import electronic governor, 7075 aircraft aluminum frame |
| propeller | 980 carbon fiber plant protection special propeller |
| Applying pesticide mission systems: | pesticide tank,Dispersion type spray system,Booster pump 1 set |
| remote control | (FUTABA 14 SG |
| power battery | High performance lithium polymer battery(44.4V/14000mA) |
| Battery special turnover box | Distribution explosion-proof battery box 1 |
| charger | lithium electricity balance charge equipment imported |
| Unmanned helicopter stable system | yes |
| Spraying system | United States imported dispersion atomization nozzle(one group*5 pcs) |
| 1 set of special maintenance tools | Unmanned aerial vehicle (uav) 1 set of special maintenance tool(including tool case ) |
| Herbicide special medicine cabinet | Fittings Selection |
| Eppo pollination special propeller | Fittings Selection |
| Unmanned helicopters carrying case | Fittings Selection |
| motor speed | 1200rpm |
| The life time of operation | 17~35min |
| Homework spray painting | 5.5~7.0m |
| fling speed | 3 -7m/s(According to the need to speed arbitrary adjustable) |
| hover | Hovering at any position direction |
| flight attitude | Any direction, reverse flight, screeching halt |
| Take-off/landing time | ≤1min |
| support the ground station whether or not | Support the automatic station(Fittings Selection) |
| dynamics performance of plane: | ≥100 thousands hours |
| Rack life | ≥5 year |
| working performance | ≥4-5 ha/h |
Figure Photos
About Us
Shandong China Coal Industrial & Mining Supplies Group Co.,ltd is a big joint stock enterprise founded in the early 1980s,registered capital is 138million yuan. The group total has 1100 employees,3 wholly owned subsidiaries and 18 professional branches.Hundreds of our products are exportedto Australia,Russia, Colombia,
Ukraine,Georgia, the United states,Southeast Asia and so on more than 60 countries and regions.
