MK Advanced Technology Glucose To F55 Production Line,
Fructose From Glucose!!!
FLOW DIAGRAM
PRODUCT SPE.
| Fructose 42% | Fructose 55% | |
| DS | 71% | 77% |
| Moisture | 29% | 23% |
| PH | 4.0-4.5 | 4.0-4.5 |
| RBU | 5 | 5 |
| Fructose Assay | 42% | 55% |
| Dextrose | 52% | 42% |
| Fe | 1 ppm | 1 ppm |
| Cu | 0.05 ppm | 0.05 ppm |
| Pb | max. 0.5mg/kg | |
| As | max. 0.5mg/kg |
DESCRIPTION
F42 section
(1) Dextrose adjustment: The dextrose is adjusted to get DS40-45% with water. It will be mixed with certain quantity chemicals then pumped to temporary storage tank as feeding of isomerization columns. The dextrose will be degassed and adjusted to qualified PH value for isomerization.
(2) Isomerization: The qualified material is sent to the isomerization columns where it will be isomerized into 42% fructose.
(3) Decoloring and filtration: The F42 is sent to the decoloring tank. In this section, active carbon is needed for decoloring at proper temperature. After decoloring, the material will be sent to the filter for filtering active carbon.
(4) Ion exchange: The F42 is sent to the ion exchanger. The tiny foreign items and bad odor is removed via ion exchanger. This equipment is used for high quality product.
(5) Evaporation: The F42 is totally cleaned through safety filter then sent to evaporator for concentrating to reach the required DS 71% as the final product.
F55 section
(6) If the final product is hfcs55, the above diluted HFCS42 can be concentrated to DS60% then sent to chromatography system for further separation. The HFCS90 can be produced via chromatography system with small brix. Then, 55% content of fructose can be acquired by means of mixing and blending the HFCS90 and HFCS42 diluted liquid. After being cleaned and evaporation, the 55% content of fructose with DS77%–the final product is produced and sent to package section.
1. Q: If I want to know the price, what info should I provide?
A: You should inform us some basic info , such as: raw material, final product, input capacity or output capacity, specifiction of material and product, etc.
2. Q: If I already have a glucose production line, can I add some machines to produce fructose?
A: That's viable, pls contact us and we can help you find a suitable solution.
3. Q: How about the automatic level?
A: Depens on you, we have manual/ semi-automatic/ full-automatic control.
4. Q: How about the installation and commissioning?
A: We can send our engineers abroad for the supervision.
5. Q: What's the capacity you can supply of the project?
A: 10000tons per year to Max.
6. Q:What's the brand of your equipments?
A: Most of them are made in China with high-quality.
Sea Worthy Package and according to the customer's requirement.
3-4 months after getting the downpayment.
1) Implementations of automation systems, computer 2D/3D modeling and advanced
CAD/CAM technology.
2) Turn-key plants for the production of wheat starch, corn starch, potato starch and
starch derivatives such as glucose, fructose, crystallized glucose, sorbitol,
etc.
3) Professional engineers with ample on-the-job training experience.
4) A team working at site for the guidance of installing, commission works.
5) Low water and low energy consumption design to save your money.
6) Equipments are made of stainless steel, one year warranty, life-long maintenance.
C-Credit: We promise only what we can do to do our customers and keep our promise.
E-Efficient: Our work is efficient based on our qualified staff and company’s standard working
process.
E-Exact: We study your requirements and supply exact solutions to you.
S-Standard: We have standard systems to guarantee our activities to be complied with
international ones.
WE ARE WHERE YOU ARE
By choosing MecKey you are choosing the perfect long-term parter for your daily operation. Our
service network can reach you wherever you are.
China
