Sand Blasting Steel Grit G80 with CE standard for surface treatment

PRIMARY PARAMETERS

Place of Origin

Shandong, China (Mainland)

Brand Name

none

Model Number

G80

Material

steel, steel

Usage

Grinding, surface treatment

Abrasive Grain Sizes

Requirment

Microstructure

Tempered Martensite or Sorbite

Colour

Black

Dimensions

0.3mm

Application

Industry

Chemical Composition

C Si Mn S P

Shape

Angular

DETAIL DESCRIPTION

Product Description

high quality Sand Blasting Steel Grit G80 with CE standard for surface treatment

China metal abrasive of cast steel shot,cast steel grit,steel cut wire shot,stainless steel shot,zic shot and copper shot

Cast Steel Grit Size:

G10,G12,G14,G16,G18,G25,G40,G50,G80,G120

Product details

Products

	Cast Steel Grit
Chemical Composition	C	0.80~1.20%
Mn	0.35~1.20%
Si	≥0.40
S	≤0.05%
P	≤0.05%
Microhardness	GP:42~52HRC GL:53~60HRC GH:60~64HRC
Hardness Deviation	Max Deviation ±3.0HRC
Microstructure	Tempered Martensite or Sorbite
Density	7.6 g/cm3

Specification of Steel Grit:

	mm	Specification of Steel Grit mm
2.5	2.0	1.7	1.4	1.2	1.0	0.7	0.4	0.3	0.2 0.2
7	2.80	all pass
8	2.36		all pass
10	2.00	80%min		all pass
12	1.70	90%min	80%min		all pass
13	1.40		90%min	80%min		all pass
16	1.18			90%min	75%min		all pass
18	1.00				85%min	75%min		all pass
20	0.850
25	0.710					85%min	70%min		all pass
30	0.600
35	0.500
40	0.425						80%min	70%min		all pass
45	0.355
50	0.300							80%min	65%min		all pass
80	0.180								75%min	65%min
120	0.125									75%min	60%min
200	0.075										70%min
325	0.045
SAE J444	G-10	G-12	G-14	G-16	G-18	G-25	G-40	G-50	G-80	G-120

Features:

In accordance with standards of GB/T18838.3-2008 Steel Shot and Steel Grit,SFSA20-66Cast Steel Abrasive, SAE J827 Cast Steel

Shot, SAE J1993High Carbon Steel Grit, YB/T5149-1993 Cast Steel Shot, YB/T5150-1993Cast Steel Grit,ISO11124-3High Carbon Cast

Steel Shot and Grit.

Remark:The 304 Austenite stainless steel shot experiecned cold drawing,cutting,grinding progress,which also makes the product with weak magnetic.

The full composition will be sent to you within 24hours once receive your message.

Quality assurance:

In purchasing, we provide products with remarkable sourcing system.
In sales, we support our customers with in-time delivery and profitable products.
In quality control and R&D, High quality products are provided to ensure the satisfaction of our customers.
In service, we treat client with honest, reliable and efficient service to develop win-win relationship.
Our Business philosophy and principle:

To be honest and sincerity
To run business of law-abiding
To create value for customers

About us

Jar Hing Products Corporation Limited

Jar Hing Products is a professional industrial supplier which offer equipments and parts service oriented for whom required precision casting equipments and parts particularly used in automotive ,construction,medical ,food industry,electric and recycle energy sectors etc with an experience of 11 years.

Jar Hing Products provide following products and services:
1.Precision casting equipments:melting furnace,injection machine,hanger shot blasting machine, table shot blasting machine, cutting machine,dewaxing machine,Manipulator for shell making,slurry machine,Evaporator,grinding machine,Sand spreading machine.water chiller,Dehumidifier,Roasting furnace,etc.
2.Precision casting raw material: mullite sand,colloidal silica,grinding belt, pattern wax,Stainless steel ball,wax cleaning liquid,wetting agent.anti foam agent,Slag Removal,etc.
3.Precision casting Parts:casting, pipe fittings, valves,fasteners, and CNC machining hardware, with mainly stainless steel,brass ,copper ,Aluminum material.

Packaging & Shipping

PACKAGE:

Standard export carton and pallet packing or as required.

DELIVERY TIME:

7-40 days after confirming order,detail delivery date should be decided according to
production season and order quantity requirements
