Features and Specifications
1. The mainframe is fitted with numeric-control system special for shearing machines.
2. The position of rear stopper is displayed in a real-time manner.
3. Multistage programming function is available and the rear stopper is able for automatic operation and continuous positioning, to achieve an automatic adjustment for position of rear stopper.
4. It is provided with counting function for shearing, to display the shearing numbers in a real-time manner, able for power-failure memory of position of rear stopper, procedures and parameters.
5. Imported ball bearing lead screw and liner guide rail are used to ensure the positioning precision, so that the processing precision of machine is higher.
Main Deployment:
1. Main motor: Siemens Germany
2. Major Low voltage electrical: Schneider France
3. Gear pump: Bosch Rexroth Germany
4. Seal ring: Valqua Japan
5. Hydraulic system: Bosch Rexroth Germany
6. CNC Controller: Delem Holland
7. Ball screw, linear guide: HIWIN Taiwan
8. Servo Motor: YASKAWA Japan
| Type | Cutting Thickness (mm) | Cutting Length (mm) | Cutting Angel (°) | Material Strength (KN/CM) | Stopper Adjust Range (mm) | Travel Times | Power (kw) | Dimension L×W×H (mm) |
| 4×2500 | 4 | 2500 | 1°30′ | ≤450 | 20-500 | 16 | 5.5 | 3040×1550×1550 |
| 4×3200 | 4 | 3200 | 1°30′ | ≤450 | 20-500 | 13 | 5.5 | 3840×1550×1550 |
| 4×4000 | 4 | 4000 | 1°30′ | ≤450 | 20-600 | 10 | 5.5 | 4600×1700×1700 |
| 4×6000 | 4 | 6000 | 1°30′ | ≤450 | 20-800 | 5 | 7.5 | 6460×2100×3200 |
| 6×2500 | 6 | 2500 | 1°30′ | ≤450 | 20-500 | 15 | 7.5 | 3040×1710×1620 |
| 6×3200 | 6 | 3200 | 1°30′ | ≤450 | 20-500 | 12 | 7.5 | 3840×1710×1620 |
| 6×4000 | 6 | 4000 | 1°30′ | ≤450 | 20-600 | 9 | 7.5 | 4620×1850×1700 |
| 6×5000 | 6 | 5000 | 1°30′ | ≤450 | 20-600 | 8 | 7.5 | 3140×1710×1620 |
| 6×6000 | 6 | 6000 | 1°30′ | ≤450 | 20-800 | 5 | 11 | 6480×2100×2300 |
| 8×2500 | 8 | 2500 | 1°30′ | ≤450 | 20-500 | 11 | 11 | 3040×1700×1700 |
| 8×3200 | 8 | 3200 | 1°30′ | ≤450 | 20-500 | 8 | 11 | 3860×1700×1700 |
| 8×4000 | 8 | 4000 | 1°30′ | ≤450 | 20-600 | 8 | 11 | 4640×1700×1700 |
| 8×5000 | 8 | 5000 | 1°30′ | ≤450 | 20-600 | 8 | 11 | 5400×2400×2000 |
| 8×6000 | 8 | 6000 | 1°30′ | ≤450 | 20-800 | 8 | 15 | 6480×2100×2350 |
| 10×2500 | 10 | 2500 | 1°30′ | ≤450 | 20-500 | 10 | 15 | 3040×1800×1700 |
| 10×3200 | 10 | 3200 | 1°30′ | ≤450 | 20-500 | 10 | 15 | 3860×2000×1700 |
| 10×4000 | 10 | 4000 | 1°30′ | ≤450 | 20-600 | 10 | 15 | 4650×2100×2000 |
| 10×6000 | 10 | 6000 | 1°30′ | ≤450 | 20-800 | 10 | 18.5 | 6500×2100×2300 |
| 12×2500 | 12 | 2500 | 2° | ≤450 | 20-600 | 12 | 18.5 | 3140×2050×2000 |
| 12×3200 | 12 | 3200 | 2° | ≤450 | 20-600 | 10 | 18.5 | 3880×2150×2000 |
| 12×4000 | 12 | 4000 | 2° | ≤450 | 20-600 | 10 | 22 | 4680×2150×2100 |
| 12×5000 | 12 | 5000 | 2° | ≤450 | 20-600 | 6 | 22 | 3245×1900×1900 |
