1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649

1/C 15KV 133% XLP MV-90 Power CableUL1072 ICEA 96 649 APPLICATIONTYPE primary underground distribution; suitable for use in wet or dry locations, direct burial,underground duct, and where exposed to sunlight. To be used at 35,000 volts or less and a

Technical Feature

  • Tianjin, China
  • 10000000FT/Month
  • L/C, T/T
  • Construction, Underground, Industrial, Installed in Raceways, Duct
  • Low and Medium Voltage Cable
  • DC & AC
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~0

PRIMARY PARAMETERS

Model NO.
MEDIUM VOLTAGE POWER CABLE MV90, MV105
Wire Core Material
Aluminum, Bare Copper Wire
Certification
ISO, CCC, RoHS, UL
Model
Medium Voltage Power Cable Mv90, Mv105
Brand
Rneda
Products Name
Medium Voltage Power Cable, Mv90, Mv105
UL Listed Type
Mv90, Mv105
Standard
UL1072, Icea S-93-639
Rated Voltage
5kv, 8kv, 15kv, 25kv, 35kv
Insulation
Tr-XLPE, Epr
Sheath
LLDPE, PVC
Working Temperture
Max 90 Degree or 105degre
Sheath with Strip
Red Strip
Insulation Level
100% or 133%
Sample Available
Yes
Trademark
RENDA
Transport Package
Reel as Your Requirements
Specification
8AWG TO 1000MCM
Origin
China
HS Code
8544492100

DETAIL DESCRIPTION

1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 6491/C 15KV 133% XLP MV-90 Power Cable
UL1072 ICEA 96 649
 1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649

APPLICATION
TYPE primary underground distribution; suitable for use in wet or dry locations, direct burial,
underground duct, and where exposed to sunlight. To be used at 35,000 volts or less and at conductor temperatures not to exceed 90/105°C for normal operation.

Applications
  • For use in power circuits up to 35 kV when installed in open air, conduit, duct, or direct buried, for wet and dry locations. Used for power applications in chemical plants, refineries, steel mills, industrial plants, utility substations and generating stations


STANDARDS & REFERENCES
Primary UD TRXLP Cable meets or exceeds the following ASTM specifications:
• B3 Soft Annealed Copper Wire
• B8 Concentric-Lay-Stranded Copper Conductors, Hard, Medium-Hard or Soft
• B230 Aluminum, 1350-H19 Wire for Electrical Purposes
• B231 Aluminum 1350 Conductors, Concentric-Lay-Stranded
• B609 Aluminum 1350 Round Wire, Annealed and Intermediate Tempers, for Electrical Purposes

UD TRXLP Cable is manufactured to the latest edition of the following specifications, and
in case of specification conflicts, in the order listed:
• ANSI/ICEA S-94-649
• AEIC CS-8
• UL1072, When Specified

CONSTRUCTION
Conductors: Bare, annealed copper per ASTM B-3,aluminum compact conductor.
Internal semiconductor:Screen over the conductor, made of thermosetting semiconductor material.
Insulation:Cross-linked polyethylene (XLPE)/Ethylene propylene rubber (EPR) , in dry atmosphere catenary tube, through a triple layer extrusion process.
External semiconductor:Screen over the insulation, made of thermosetting and strippable semiconductor material.
Metallic screen:Screen of copper wires.
External sheath:PVC, red or black colour.LLDPE

Temperature Range: -40°C to +90/105°C
Voltage Rating: 5KV 8KV 15KV 25KV 35KV
Phase Conductor Neutral Thickness Per Cond. (mils) Diameter (mils) Weight 1000 feet (lbs.)  Allowable Ampacities+
Size (AWG or kcmil)  Strand-ing No. of Wires  Size (AWG) Nominal Insul. Insul. Shield min. Point Approx. Jkt. Bare Phase Cond. Over Insul. Over Insul. Shield Comp. Cable Comp. Cable Direct Burial In Ducts
ALUMINUM CONDUCTOR - 100% INSULATION LEVEL
2Solid 10141753050258653733961453168* 119*
2710141753050283678758986470168* 119*
1Solid 13141753050289685765993520193* 137*
119131417530503227187981026539193*  137*
1/0 Solid 161417530503257208001028591218*  155*
1/0 19161417530503527488281056609218*  155*
2/0 19201417530503957908701098703248*  177*
3/0 19251417530504438389181146817284*  201*
4/0 19201217530504988939731234993324*  230*
2503716101753050558963104313461213360* 257*
35037181417540506611068116813961055389** 319**
50037251417540507891193129315211349468** 384**
75061241217540809681383148317981946569** 468**
1000612010175408011171530163019882473642** 542**
1250912510220558012501765189522533142688** 604**
1500913010220558013701885201523733616726** 637**
UL Certificate for 35KV URD Cable(MV90/105)
SOOW CORDS, XHHW,SER,SEU,MC Cable

1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649

COMPANY INFORMATION
Hebei Huatong Wires and Cables Group Co., Ltd.It was established in 1993.
Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 1000 employers in our company, among which more than 150 are technicians.
TWO FACTORIES IN CHINA ! ONE FACTORY IN Tanzania!
Yearly Export Amount 200Millon

Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects.
We are top cable manufacture of rubber serious cables . Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC power cables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We are OEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.
1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649
UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
Certificates and"National Industrial Production License", "Certificate of Recommended Enterprises and Products for National Grid", "Adopting International Standard Certificate", and "High-Tech Enterprise Certificate", "Certificate of High Quality Products", "Certificate of Scientific and Technological Achievements", "Qualified Supplier Certificate", "China Classification Society Certificate of Works Approval", "Det Norske Veritas Type Approval Certificate", "Railway Product Certificate", "Safety Certificate of Approval for Mining Products", "National Mandatory Product Certification", "Certificate for China Compulsary Products Certification" and "Practical New-Type Patent Certificate".
1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649



1/C 15kv 133% Xlp Mv-90 Power Cable UL1072 Icea 94 649


Our Service
1.24years production experience and 15 years export experience .
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3.OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback  Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7. Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.

FAQ
1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgentto get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express  account or prepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
