Rx27 Ceramic Encased Wire Wound Cement Power Resistors
RX27 type cement resistors are dielectric strength, weldability strong, various specifications, widely use.
Factory & Workshops:
Company Certificates:
Main Customers:
Packing & Shipping:
Our Advantages:
(1).A long history (27years) on producing resistors and inductors!
(2).True factory with Factroy direct price!
(3).Fastest Lead Time
(4). Low Minimum order quantity!
(5). Regular purchase with competitive prices and reliable supply !
(6). Warranty is At Least 2 years!
(7). New Original & PB Free!
========================================================
Please contact me for more details if you have reference inquiries, different appreance is also customied designed by our engineers!
Ms.Coco Wen
Mob:8613915084415
Tel:86-519-83280538-8017 Fax:86-519-83295710
Welcome to provide us your spec., we will submit our best quotation shortly!
==========================================================
RX27 type cement resistors are dielectric strength, weldability strong, various specifications, widely use.
Products | Cement type resistors (LW) | ||||||
Specifications | |||||||
Part NO. RX | Dimensions | Resistance range | |||||
W± 1 | H± 1 | L± 1.5 | C± 3 | D± 0.05 | KN | MO | |
2W | 7 | 7 | 18 | 30 | 0.8 | 0.1~270 | 271~33K |
3W | 8 | 8 | 22 | 35 | 0.8 | 0.1~1K | 1K1~47K |
5W | 10 | 9 | 22 | 35 | 0.8 | 0.1~1K | 1K1~68K |
7W | 10 | 9 | 35 | 35 | 0.8 | 0.1~1K | 1K1~68K |
10W | 10 | 9 | 48 | 33 | 0.8 | 0.1~1K | 1K1~50K |
15W | 12.5 | 11.5 | 48 | 33 | 0.8 | 0.1~1K | 1K1~150K |
20W~25W | 14 | 13.5 | 60 | 33 | 0.8 | 0.1~1K | 1K1~150K |
| Rated Power | 2W | 3W | 5W | 7W | 10W | 15W | 20W~25W |
Max. working voltage | 150V | 350V | 350V | 500V | 750V | 1000V | 100V |
Dielectric withstanding voltage | 1000V (AC) | 1000V (AC) | 1000V (AC) | 1000V (AC) | 1000V (AC) | 1000V (AC) | 1000V (AC) |
Resistance tolerance | J± 5% | J± 5% | J± 5% | J± 5% | J± 5% | J± 5% | J± 5% |
Cement Type Resistor (wire wound) | |||||||
Characteristics | Specifications | Test Method | |||||
DC Resistance JIS-C-5202 5.1 | J ± 5% | AT 25° C | |||||
Dielectric withstanding voltage JIS-C-5202 5.7 | No evidence of flashover mechanical amage, arcing or insulation breakdown. | Resistance shall be clamped with a conductive material which conforms to resistors surface so that 90 o of the outer periphery is contacted a potential of 1000V AC shall be applied for 60 seconds. | |||||
Insulation Resistance JIS-C-5202 5.6 | 1000MΩ MIN | Withstanding test and shall be measured at DC 500V. Resistor shall be prepared AC same method of dielectric. | |||||
Thermal Shock | Δ R≤ ± (2%R0+0.1Ω ) | After application of rated power for 30 minutes, 30 minutes exposure to -30± 5° C ambient temperature. | |||||
Humidity JIS-C-5202 7.5 | Δ R≤ ± (2%R0+0.1Ω ) | Temperature resistance change after 1000 hours exposure in a humidity test chamber controlled at 40± 2° C and 90~95% relative humidity. | |||||
Cement Type Resistor (metal oxide film) | |||||||
Short time overload | Δ R≤ ± (2%R0+0.05Ω ) | Temperature resistance change after the application of a potential of 2.5 times RCVW for 5 seconds. | |||||
Load Life JIS-C-5202 7.10 | Δ R≤ ± (5%R0+0.1Ω ) | Permanent resistance change after 1000 hours operating at RCWV, with duty cycle of 1.5 hours on and 0.5 hours off at 25° C± 2° C. | |||||
Load Life in Humidity JIS-C-5202 7.9 | Δ R≤ ± (5%R0+0.1Ω ) | Temperature resistance change after 1000 hours(1.5hours on and 0.5 hours off) at RCVW in a humidity chamber controlled at 40± 2° C and 90~95% relative humidity. | |||||
Solderability JIS-C-5202 6.5 | 95% coverage MIN | Test temperature of solder: 230± 5° C Dwell time in solder: 3± 0.5 SEC | |||||
Nonflammability | Nonflammable | Load 5 min according to 5times, 10 times, 16 times rated power and A. C. respectively. |
