Machine Control Receiver Supereye 3 & Control Box YD998B

With the SUPEREYE 3 Machine Control Receiver and YD998B Control Box installed in your machine you will be able to:
* Make the excavation easy and simple, improve the leveling work
* High working efficiency
* High leveling accuracy
* Save the labor and time

Machine Control Receiver Supereye 3
Features of Machine Control Receiver Supereye 3:
* Input power: DC 12V
* 360-degree receiving window can find the laser signals from all angles
* Accuracy: Fine: ± 2.5mm ~ ± 15mm; Coarse: ± 5mm ~ ± 30mm
* Operating range: 400m radius
* Easy to install, and can be easily moved from one machine to another machine.
* Quick detecting, capable of displaying five positions of the laser
* High-bright LEDs, easy to see working state of the receiver under any condition, Green light means the laser is centered.
* Large Receiving window with range of 270mm.

Control Box YD998B
Features of Control Box YD998B:
* Input power: DC 10-30V
* Switch for ON/OFF ON INDICATOR Lamp ON OFF INDICATOR Lamp OFF
* Automatically control the blade moves up and down
* Switch for Manual control & Automatic control
* LED Light and dark adjustment switch: Bright or Dim
* Time Counter
* Can display five positions of the laser with additional manual adjustment

Specifications of Control Box YD998B:
* Input power: DC 10-30V
* Beam Reception: 360 degrees
* Operating Range: 400m radius
* Accuracy: Fine: ± 2.5mm ± 15mm Coarse: ± 5mm~± 30mm
* Display adjustor: Bright or Dim
* Out of Beam Indication: On or Sparkle
* Shipping Dimensions: 520× 320× 395mm(L× W× D)
* Shipping Weight: 10Kg(Carry case for whole kit), 2.6Kg(SUPEREYE 3), 3Kg(YD998B)
* Mounting Pipe: 38mm to 45mm(round tube)
* Environment: Waterproof, Dustproof to IP66
* Operating Temperature: -4° F to 140° F(-20° C to 60° C)

Pictures of Machine Control System:
