Basic info :
These items are widely applied in in coating, lighting, refrigeration, vacuum drying, freeze-drying, solar energy, analytical instruments, leak detection equipment, packaging, heat treatment, metallurgy etc.
==Low noise, low vibration, long period of service time with no rotary vane spring,
==Using the built-in oil check valve so that oil will not return
==With a built-in pump oil forced, to realize continuous and stable operation for a long time At atmospheric pressure
These items are widely applied in in coating, lighting, refrigeration, vacuum drying, freeze-drying, solar energy, analytical instruments, leak detection equipment, packaging, heat treatment, metallurgy etc.
==Low noise, low vibration, long period of service time with no rotary vane spring,
==Using the built-in oil check valve so that oil will not return
==With a built-in pump oil forced, to realize continuous and stable operation for a long time At atmospheric pressure
| Parameters / Item | BSV16 | Unit | |
| Pump Speed | 50HZ | 240 | L/min |
| 60HZ | 290 | ||
| Pressure | Gasballast(on) | 5*10^(-1) | Pa |
| Gasballast(off) | 5 | ||
| Motor Power | 380V (three phase) | 0.55 | kW |
| 220V (single phase) | |||
| Oil required | 1.2 | L | |
| Diameter of Inlet/Outlet | KF25 | DN | |
| Weight | 27 | Kg |
