Product Description
The major products in our company is stainless steel pipe making machine including industrial pipe making machine,automotive exhaust pipe making machine,large caliber oil pipe making machine,water pipe making machine, heat-exchange pipe making machine,precision composite pipe making machine,high precision mould,polishing machine,bright solution equipment,shear welder and cutting blade,which gain a leading position in the industry.
Main parameter
Main features:
1.High level intelligent industrial pipe making machine.
2.Good welding mechanical properties.
3.High finished rate with low product cost.
4.Users-friendly and easy to maintain.
5.Well-structured and complete in specification.
strengths
excellent geographic location
Be in traffic fortress,connecting home and abroad.Easy to contact customers deeply and satisfy their demand.At the same time,the convenient transportation cut the logistics cost quite drastically,that means a lot for buyers to reduce purchase cost.
New-age industrial welding pipe making machine is mature in technology,and the technique is delicate,which is well-known home and abroad for the characteristics of high intelligence,easy-adjusted,superior property and high precision.
Delivery & packaging
Export standard's Package in the global market: Use stranded wire and bracket to secure the large machinery . And use shock-film to protect the external main motor. Use container to pack the whole pipe manufacture machine, and the container size depends on the machine's total length. In addition, the stainless steel moulds will be protect by waterproof membrane and earthquake film into the wooden boxes. The scattered part of the machine's part use bulk transport.
HOW TO CONTACT US
contact person:Ms.brisk
Tel:+86 18173517903
The major products in our company is stainless steel pipe making machine including industrial pipe making machine,automotive exhaust pipe making machine,large caliber oil pipe making machine,water pipe making machine, heat-exchange pipe making machine,precision composite pipe making machine,high precision mould,polishing machine,bright solution equipment,shear welder and cutting blade,which gain a leading position in the industry.
Main parameter
| Model number | ZG30 | ZG40 | ZG50 | ZG60 | ZG80 | ZG100 | ZG120 |
| Horizontal axis(mm) | 30 | 40 | 50 | 60 | 80 | 100 | 120 |
| range(mm) | Φ6-Φ26 | Φ12-Φ38 | Φ31-Φ63 | Φ38-Φ89 | Φ63-Φ159 | Φ101-Φ219 | Φ159-Φ325 |
| thickness(mm) | 0.2-1.0 | 0.3-2.5 | 0.4-3.0 | 0.5-4.0 | 1.0-6.0 | 1.5-8.0 | 2.0-10.0 |
| speed(m/min) | 0.5-6.0 | 0.4-5.0 | 0.4-4.0 | 0.4-3.0 | 0.4-2.5 | 0.3-2.0 | 0.3-1.0 |
| pipe length(m) | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| main motor power(kw) | 4*2 | 5.5*2 | 7.5*2 | 11*2 | 15*2 | 22*2 | 30*2 |
| grinding motor power(kw) | 3*3 | 3*3 | 3*3 | 3*3 | 3*3 | 3*3 | 3*3 |
| cutting motor power(kw) | 1.1/1.5 | 1.1/1.5 | 1.5/2.2 | 1.5/2.2 | 2.5 | 2.5 | 2.5 |
| welder current(A) | 350-400 | 350-400 | 400-500 | 500-600 | 600A+plasma welder | 600A+plasma welder | 600A+plasma welder |
| host length(mm) | 7200 | 7900 | 9000 | 9500 | 15000 | 19000 | 24000 |
| main accessories | feeding rack,grinding head,cutting machine,storage rack. |
Main features:
1.High level intelligent industrial pipe making machine.
2.Good welding mechanical properties.
3.High finished rate with low product cost.
4.Users-friendly and easy to maintain.
5.Well-structured and complete in specification.
strengths
excellent geographic location
Be in traffic fortress,connecting home and abroad.Easy to contact customers deeply and satisfy their demand.At the same time,the convenient transportation cut the logistics cost quite drastically,that means a lot for buyers to reduce purchase cost.
Elite team
We have professional R&D group and experienced technical talents as well as high-quality administrator.Our production equipment and facilities are sound.And we focus on creating perfect quality and in building up top brand in stainless steel pipe making machine.New-age products
New-age industrial welding pipe making machine is mature in technology,and the technique is delicate,which is well-known home and abroad for the characteristics of high intelligence,easy-adjusted,superior property and high precision.
Pursuit for excellence
In order to satisfy customers' demand better,we never hold our step to innovate.Integrating R&D,design,sales,service,we provide customers with high-quality products as well as good purchasing experience.And you will find it's totally right to cooperate with us.Delivery & packaging
Export standard's Package in the global market: Use stranded wire and bracket to secure the large machinery . And use shock-film to protect the external main motor. Use container to pack the whole pipe manufacture machine, and the container size depends on the machine's total length. In addition, the stainless steel moulds will be protect by waterproof membrane and earthquake film into the wooden boxes. The scattered part of the machine's part use bulk transport.
HOW TO CONTACT US
contact person:Ms.brisk
Tel:+86 18173517903
China
