1. GENERATOR DATA
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
2. MAIN SPECIFICATION
| Genset Model | KPC1375 | KPC1500 | KPC1650 | KPC1718 | |
| Rated Power | KW/KVA | 1000/1250 | 1100/1375 | 1200/1500 | 1250/1560 |
| Standby Power | KW/KVA | 1100/1375 | 1200/1500 | 1320/1650 | 1375/1718 |
| Rated Voltage | V | 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V | |||
| Speed | RPM | 1500/1800 | |||
| Rated frequency | Hz | 50/60 | |||
| Engine Model | KTA50-G3 | KTA50-G8 | KTA50-GS8 | KTA50-G9 | |
| Engine Power | KW | 1227 | 1429 | 1429 | 1656 |
| Air intake way | Turbo | Turbo | Turbo | Turbo | |
| Governor | Electronic | Electronic | Electronic | Electronic | |
| Cylinder | QTY | 16 | 16 | 16 | 16 |
| Bore*Stroke | mm*mm | 159×159 | 159×159 | 159×159 | 159×159 |
| Displacement | L | 50.3 | 50.3 | 50.3 | 50.3 |
| Fuel Consumption | g/kw.h | 197 | 205 | 204 | 203 |
| Compression Ratio | 13.9:1 | 14.9:1 | 14.9:1 | 13.9:1 | |
| Alternator Model | STF-634G | STF-734B | STF-734B | STF-734C | |
| Voltage Regulation | AVR | ||||
| Excitation Method | Brushless | ||||
| Open Type Size | mm | 4850x2000x2320 | 4980x2000x2350 | 4980x2000x2350 | 5200x2150x2400 |
| Open Type Weight | kg | 7800 | 8200 | 9500 | 10000 |
| Soundproof Size | mm | 6000x2200x2600 | 6000x2200x2600 | 6000x2200x2600 | 7000x2300x2650 |
| Soundproof Weight | kg | 9800 | 10800 | 12300 | 13600 |
3. PRODUCT FEATURES
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
