With Cummins 160kVA Silent Electricity Power Generator 1.CE;BV;ISO90012.global warranty3.fastest delivery4.good price and high quality Generally Information for Cummins 6CTA8.3-G2 Diesel EngineEngine Model6CTA8.3-G2Engine Type6 Cylinders Displa

Technical Feature

  • Guangzhou, China
  • 100 Sets Per Month
  • L/C, T/T, D/P, Western Union
  • Basic Diesel Generator
  • Fixed
  • Four Stroke
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Model NO.
LFS160kVA
Conditions of Use
Land Use
Usage
Common Units
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Brand
Laurel
Warranty
24 Months or 1200 Operating Hours
Rated Power
20kw/25kVA
Frequency
50/60Hz
Rated Voltage
400/230;380/220;etc.
Trademark
Laurel
Transport Package
Plywood or Nude Packing as Your Choice
Specification
CE; ISO
Origin
China
HS Code
8502110000

DETAIL DESCRIPTION

With Cummins 160kVA Silent Electricity Power Generator

1.CE;BV;ISO9001
2.global warranty
3.fastest delivery
4.good price and high quality


Generally Information for Cummins 6CTA8.3-G2 Diesel Engine
Engine Model6CTA8.3-G2
Engine Type6 Cylinders
Displacement8.3 L
Bore*Stroke(mm)114 * 135
 Weight 2780 Kg
Overall Diemension(L*W*H)3000mm*1150mm*1800mm

Technical Specification for Cummins 6CTA8.3-G2 Diesel Engine
Fuel SystemA Type Fuel Pump
AspirationTurbocharged
Governing SystemElectronic
Electrical System(Starter Motor/Alternator)12V/24V
Exhaust temperature570ºC
Bottom shell oil capacity24 L

Performance Data for Cummins 6CTA8.3-G2 Diesel Engine
Max Power180kW/244HP
100% Load(Standby)215g/kw.h
75% Load(Standby)211g/kw.h
50% Load(Standby)216g/kw.h
Oil Capacity27.6L
Coolant Capacity34L
 Speed1500-1800 rpm

The specification of alternator:
Brandwith Stamford, Leroy semor, Maraton etc.
RegulatorAVR automatic voltage regulating
ExcitationBrushless, self-excitation
Connecting type3Phase 4 Wire, Y type
Tel.Influence Factor TIF<50
Tel.Harmonic Factor TIF<2%
Steady voltage≤±1%
Insulation degreeH degree
Exclosure degreeIP23

Our main products:
We are engaged in the production and sale of diesel generator sets, generators, engines, water pumps and other agricultural machinery products. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.

Guarantee Service
We have 34 years of export experience. We deliver not only our products, but also our value-added technical support and after-sales service. We ensure that all our original purchasers get Laurel & Honesty Holdings products guarantee under this warranty statement.

Warranty Period
We will provide a warranty period of 24 months or 1200 operating hours to the original purchasers for all our Diesel associated products, and a warranty period of 12 months or 1000 operating hours to the original purchasers for all gasoline associated products. The warranty period starts from the day of delivery to the original retail purchaser.
