110kV,66kV series power transformer
Product description
110kV oil immersed on-load voltage regulation power transformer has a series of big changes in material, technical and construction with the characters of small size, light weight, high efficiency with low loss and low noise, stable operable operation which cutting down large number of loss from energy GRID and minimizing operation charge, improving the industrial economic benefit. It is used in power plant, transformer substation, big-sized and chemistry factory and etc. the product is according to national and IEC standards.
Main technical data for 66kV level S(F)9,S(F)10,S(F)11
3-phase transformer with no-load tap changer
Main technical data for 110kV level S(F)9,S(F)10,S(F)11 series three-phase two winding transformer with no-load tap changer
ATTENTION:
1.The payment term: We accept TT,30% deposit and 70% balance against copy of BL.
2.The delivery time: Usually it will take about 15-20 days.
3.The standard of package: Usually use strong plywood case for protection.
4.The material of transformer: We have two types, one is with copper and another one is with aluminum. It depends on your requirement. In fact, those two have difference if normal work well. Only except the long life. Copper is better and also higher price.
5.The logo: If you have good quantity, it absolute no problem to do OEM.
6.Our market: our products are popular in Indonesia, Philippines, Russia, USA, Middle East and so on. Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation..
7.Warranty: in 12 month since BL date.
OUR SERVICE:
1.quick response in before sales period help you got order.
2.excellent service in production time let you know each step we made.
3.reliable quality solve you after sale headache.
4.long period quality warranty ensure you can buy without hesitate.
WHY CHOOSE POWERTECH:
1. One-stop supplier globally.
2. More than 10 years professional experiences in electrical appliance industry.
3.We offer professional online technology support for perfecting your electrical solution free.
4. Experienced sales service and suggestion.
5. All the products with accessories under strict quality control and final inspection before shipping.
6. We can assure the powerful competitive price and reliable quality products.
7. Most competitive shipping rate from our own shipping forwarder.
8. Warranty assurance: 12 month
9. Whatever big or small order, we can provide you one-to-one service.
CONTACT US:
Contact person: Mr. Chen Chengming
Tel:86-570-5657760
Mobile:86-18668777248
Your Best Choice for Electrical Appliances Industry!!!
Please leave an inquiry to know more details about Price , Packing ,Shipping and Discount.
Product description
110kV oil immersed on-load voltage regulation power transformer has a series of big changes in material, technical and construction with the characters of small size, light weight, high efficiency with low loss and low noise, stable operable operation which cutting down large number of loss from energy GRID and minimizing operation charge, improving the industrial economic benefit. It is used in power plant, transformer substation, big-sized and chemistry factory and etc. the product is according to national and IEC standards.
Main technical data for 66kV level S(F)9,S(F)10,S(F)11
3-phase transformer with no-load tap changer
| Rated power (kVA) | High voltage (kV) | H.V.Tap(kV) | Low voltage (kV) | Vector group | Short- circuit impedance (%) | No-load Loss (W) | On-load Loss (W) | No-load current (%) | ||||
| 9 The 9 type of loss | 10 The 10 type of loss | 11 The 11 type of loss | 9 The 9 type of loss | 10 The 10 type of loss | 11 The 11 type of loss | |||||||
| 6300 | 63 66 69 | ±2×2.5% | 6.3 6.6 10.5 11 | YNd11 | 9 | 9.5 | 8.5 | 7.5 | 36 | 34 | 34 | 0.63 |
| 8000 | 11.4 | 10.2 | 9 | 42.8 | 40.4 | 40.4 | 0.63 | |||||
| 10000 | 13.5 | 12.1 | 12.1 | 50.4 | 47.6 | 47.6 | 0.75 | |||||
| 12500 | 15.9 | 14.2 | 12.6 | 59.9 | 56.5 | 56.5 | 0.53 | |||||
| 16000 | 19.1 | 17.1 | 15.1 | 73.53 | 69.5 | 69.5 | 0.49 | |||||
| 20000 | 22.6 | 20.3 | 17.9 | 89.1 | 84.2 | 84.2 | 0.49 | |||||
| 25000 | 26.7 | 23.9 | 21.1 | 105.3 | 99.5 | 99.5 | 0.42 | |||||
| 31500 | 31.8 | 28.4 | 25.1 | 126.9 | 120 | 120 | 0.42 | |||||
| 40000 | 38 | 34 | 30 | 148.5 | 140.3 | 140.3 | 0.39 | |||||
| 50000 | 44.9 | 40.1 | 35.4 | 184.5 | 174.3 | 174.3 | 0.39 | |||||
| 63000 | 53.3 | 47.7 | 42.1 | 222.3 | 210 | 210 | 0.39 |
Main technical data for 110kV level S(F)9,S(F)10,S(F)11 series three-phase two winding transformer with no-load tap changer
| Rated power (kVA) | High voltage (kV) | H.V.Tap(kV) | Low voltage (kV) | Vector group | Short- circuit impedance (%) | No-load Loss (W) | On-load Loss (W) | No-load current (%) | ||||
| 9 The 9 type of loss | 10 The 10 type of loss | 11 The 11 type of loss | 9 The 9 type of loss | 10 The 10 type of loss | 11 The 11 type of loss | |||||||
| 6300 | 110 121 (132) | ±2×2.5% | 6.3 6.6 10.5 11 (20) (34.5) | YNd11 | 10.5 | 9.5 | 8.5 | 7.5 | 36.9 | 34.9 | 34.9 | 0.69 |
| 8000 | 11.4 | 10.2 | 9 | 45 | 42.5 | 42.5 | 0.69 | |||||
| 10000 | 13.3 | 11.9 | 10.5 | 53.1 | 50.2 | 50.2 | 0.64 | |||||
| 12500 | 15.7 | 14.1 | 12.4 | 63 | 59.5 | 59.5 | 0.64 | |||||
| 16000 | 19 | 17 | 15 | 77.4 | 73.1 | 73.1 | 0.59 | |||||
| 20000 | 22.6 | 20.2 | 17.8 | 93.6 | 88.4 | 88.4 | 0.59 | |||||
| 25000 | 26.6 | 23.8 | 21 | 110.7 | 105 | 105 | 0.54 | |||||
| 31500 | 31.7 | 28.4 | 25 | 133.2 | 126 | 126 | 0.54 | |||||
| 40000 | 37.8 | 33.9 | 29.9 | 156.6 | 148 | 148 | 0.59 | |||||
| 50000 | 44.7 | 40 | 35.3 | 189 | 178.5 | 178.5 | 0.52 | |||||
| 63000 | 53.1 | 47.5 | 41.9 | 234 | 221 | 221 | 0.48 | |||||
| 75000 | 12-14 | 59 | 53.1 | 47.2 | 278 | 264.1 | 264.1 | 0.38 | ||||
| 90000 | 68 | 61.2 | 54.4 | 320 | 304 | 304 | 0.34 | |||||
| 120000 | 84.8 | 76.4 | 67.9 | 397 | 377.2 | 377.2 | 0.31 | |||||
| 150000 | 100.2 | 90.2 | 80.2 | 472 | 448.5 | 448.5 | 0.27 | |||||
| 180000 | 112.5 | 101.3 | 90 | 532 | 505.4 | 505.4 | 0.23 |
ATTENTION:
1.The payment term: We accept TT,30% deposit and 70% balance against copy of BL.
2.The delivery time: Usually it will take about 15-20 days.
3.The standard of package: Usually use strong plywood case for protection.
4.The material of transformer: We have two types, one is with copper and another one is with aluminum. It depends on your requirement. In fact, those two have difference if normal work well. Only except the long life. Copper is better and also higher price.
5.The logo: If you have good quantity, it absolute no problem to do OEM.
6.Our market: our products are popular in Indonesia, Philippines, Russia, USA, Middle East and so on. Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation..
7.Warranty: in 12 month since BL date.
OUR SERVICE:
1.quick response in before sales period help you got order.
2.excellent service in production time let you know each step we made.
3.reliable quality solve you after sale headache.
4.long period quality warranty ensure you can buy without hesitate.
WHY CHOOSE POWERTECH:
1. One-stop supplier globally.
2. More than 10 years professional experiences in electrical appliance industry.
3.We offer professional online technology support for perfecting your electrical solution free.
4. Experienced sales service and suggestion.
5. All the products with accessories under strict quality control and final inspection before shipping.
6. We can assure the powerful competitive price and reliable quality products.
7. Most competitive shipping rate from our own shipping forwarder.
8. Warranty assurance: 12 month
9. Whatever big or small order, we can provide you one-to-one service.
CONTACT US:
Contact person: Mr. Chen Chengming
Tel:86-570-5657760
Mobile:86-18668777248
Your Best Choice for Electrical Appliances Industry!!!
Please leave an inquiry to know more details about Price , Packing ,Shipping and Discount.
