Description: 6 stage RO system with T33-10
Capacity: 50/75/100GPD
Flush Type: Auto Flush
Housing: KK-FS-10-02 10"double"O" ring housing
Fitting Type: JACO or Quick Fitting
Diaphragm Booster Pump with Adaptor 110/220V, 50/60Hz
RO Membrane: VONTRON or CSM or FILMTEC or FCS Membrane
Faucet: Can be choosen in faucet page
Pressure Tank: 3.2G Plastic Tank
Unit packing Dimension: 41*35*58cm
Feature
High Grade RO membrane separation technology.
Food grade material ensure safest water.
Able to connect to water dispenser to building a healthy & safety drinking system.
The outlet water after purification is directly drinkable.
It adopts membrane with American space technology, and applies the advanced international technique of reverse osmosis(RO)membranceto produce pure water.
²6
stages filtration, eliminates the sediment, suspended solid, colloid, organic compounds, heavy metal, soluble solid, bacteria, virus, pyrogenetic bacterium and other harmful substances in the original water, retains only water molecule and dissolved oxygen.
²It adopts famous import mute and high pressure pump, with long service life and reliable quality.
²Interchangeable pretreatment filter, effectively guarantees the pretreatment effect; easy interchange, economical filter-core price, with low cost to produce water.
²With the function of high pressure flash reverse osmosis membrane, effectively extends the service life of RO membrane.
²Automatic control of water-producing process (the machine will shutdown when the original water lacks or the water tank is full of water).
| Stage | Description | Component Item No. | Function |
| 1st | 5um pp Spun Fiber | PP-10" | Remove the particles, dust, mud etc. |
| 2nd | Granular Carbon Filter | GAC-10" | Remove the chlorine, organics, odor, smell turbidity etc. |
| 3rd | Block Carbon Filter | CTO-10" | Remove the chlorine, odor, smell and suspending particles. |
| 4th | RO membrane | VONTRON or CSM or FCS or FILMTEC | Remove the bacteria, heavy metal, salt, bad mineral substance and other dissolved matter and chemical drug in the running water |
| 5th | Post inline Carbon Filter | T-33 | Adjust the taste. |
