oil filter press machine for slurry dewatering
The plate and frame fitter can give extremely wide applications, such as the alcohols (fruit wine, port wine, health wine, yellow rice wine, beer, white spirit, and some others), the liquid medicines beverages,
soy sources, vinegar, honey, syrups, various oils, and chemical products, among others. The required
effect like coarse filtration, refined filtration, microfilter, terilization, and more can be achieved by selecting
different precision of filter materials.
Product Feature
It has the following features: stable performance, high automation, safe and reliable, easy to operate, backwashing can be realized.
Product Application
coal washing
inorganic salt
mining
alcohol
petroleum
dyestuff
metallurgy
pharmaceuticals
foodstuff
printing and dyeing
paper making
sewage treatment
Specifications
specification | 15/630 | 30/630 | 50/800 | 80/800 |
| filter area (m2) | 15 | 30 | 50 | 80 |
| thickness of filter cake(mm) | 30 | 30 | 30 | 30 |
| quantity of filter plate | 18 | 37 | 38 | 62 |
| volum of filter chamber(L) | 226 | 452 | 748 | 1210 |
| filter pressure(MPa) | 0.6 | 0.6 | 0.6 | 0.6 |
| power (kw) | 2.2 | 2.2 | 3.0 | 3.0 |
| size (m) | 2.82*1.11*1.19 | 3.96*1.11*1.19 | 4.615*1.26*1.35 | 6.295*1.26*1.35 |
Company infomation
We specialized in more than 50 series and 200 kinds of specifications of sewage disposal environmental protection equipments , which contains Dissolved air flotation machine, domestic sewage treatment equipment,anaerobic reactor, sludge
dewatering machine series, vacuum filter, sludge scraper garbage incinerator etc.environmental equipment, Enjoying a great reputation in
domestic. Advanced technology, Scientific and standardized management, Professional marketing team, which make your choices without worries.
