Product Application
This series of dry heat sterilizer is used for depyrogenation of high temperature bearing items after cleaning by cuccessive circulation of high temperature air. It is widely used for the high-temperature sterilization operation of injection ampoule, vials, oral liquid bottles and other medical glass bottles and stainless steel utensils in pharmaceutical factories
Main Features
This series of dry heat sterilizer adopts horizontal rectangular structure, 304 or 316L stainless steel chamber, and covered by the external plate that is made by draw-benched stainless steel. And the equipment is accessorized with standard GMP verification interface. Industrial control system PLC+ HMI has a standard "user management, data storage, process management" function, the sterilization process can be traced back, with independent data logging device and industrial control system to ensure data accuracy.
| Model | Volume | Inner size | Out size | Heat power | Circulation power | Replenish power | Dehumidifcation fan power |
| DMH0.25 | 0.25m³ | 500*600*800 | 850*1700*2000 | 9kw | 1.1kw | 0.06kw | 0.18kw |
| DMH0.36 | 0.36m³ | 800*600*600 | 1150*1900*2100 | 11kw | 2.2kw | 0.18kw | 0.25kw |
| DMH0.6 | 0.6m³ | 800*800*1000 | 1150*1900*2100 | 19kw | 2.2kw | 0.18kw | 0.25kw |
| DMH0.8 | 0.8m³ | 1500*610*910 | 1800*1320*1950 | 21kw | 3.0kw | 0.18kw | 0.37kw |
| DMH1.2 | 1.2m³ | 1500*680*1180 | 1820*1420*2000 | 27kg | 4.0kw | 0.25kw | 0.75kw |
