Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges

PSD Bag Lifting Top Discharge Food CentrifugePlatform Bag Lifting Top DischargeCentrifuge                _______________________________________________________________________________             Product DescriptionManual Top Discharge

Technical Feature

  • 1 Set
  • Shanghai, China
  • 100 Sets/Month
  • L/C, T/T, Western Union
  • Frequency Inverter Control
  • Manual Batch Operation
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~0

PRIMARY PARAMETERS

Model NO.
PSD
Discharge
Pocket Top Lifting Discharge
Application
Food Centrifuge
Trademark
Huada
Transport Package
Standard with Wooden Pallet and Poly Film Wrapping
Origin
China
HS Code
8421199090

DETAIL DESCRIPTION

PSD Bag Lifting Top Discharge Food Centrifuge


Platform Bag Lifting Top Discharge
Centrifuge

_______________________________________________________________________________

Product Description

Manual Top Discharge Centrifuge in Production Video:

http://www.huada-video.com/PSD-Series




Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges


Once the materials to be separated enter the fast-spinning basket, it will be filtrated by the filter liner under the centrifugal force. The liquid flows out through the liquid outlet, but solids deposit on the internal wall of the basket. Once the solid cake reaches the rate capacity, feeding stops. Wash the solids cake, and then drain out the washing water. Finally stop the machine. Use the lifting tool or crane to lift out the filter cloth with solid cake, and move to the discharging place. Open the filter cloth and discharge the solid cake. Put the filter cloth back to the centrifuge and move to next batch.

Main applications


Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges


Apply to separating material with granulate particle shape, but also fibers, like plasters, bluestone, potassium chloride, borax, dyestuffs, pesticides, salts, gourmet powders, foodstuff additives, chemical flavors, antibiotics, vitamins, the metals like copper, zinc and aluminum, metal products, sludge, etc.
Diagram
Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges

Main features

1,Inverter start-up, smooth starting, adjustable relative centrifugal force.
2,Discharge cake by lifting out filter cloth is highly efficient with low labour intensity; No damage to the particles; Wide range of applications.
3,Well-designed structure and polished surface leaves no residual heel. With big hinged cover, it is easy to clean the gap between the case and the basket.
4,Overall welding structure between the base and the case ensures high carrying strength.
5,Platform base design lowers the center of gravity and requires minimum installation space. The platform base can be used for operation platform.
6,Liquid-damping vibration isolators, simplify the routine maintenance.
7,Big hinged cover, feed pipe, wash pipe, observation glass and light.
8,Automatic CIP system cleans the internal surface of the case, the basket and liquid slot to meet the clean requirement in accordance with GMP standards.
9,Tightness structure with silicone rubber or fluoroelastomers seals. Nitrogen protection system(optional)is for anti-explosion applied to poisonous, flammable and explosive environment.
10,Equipped with hydraulic suspension arms with external fully-stainless steel surface (optional), which is easy for discharging and complies with the sanitation requirements.

Parameters
Items
Models
PSD800
PSD1000
PSD1200
PSD1250
PSD1500
PSD1600
PSD1800
Basket Dia (mm)
800
1000
1200
1250
1500
1600
1800
Basket Volume (L)
120
200
330
400
600
800
910
Max. Load (kg)
150
250
410
500
800
1000
1100
Max. Rotating speed (r/min)
1200/1500
1100/1200
960/1050
1000/1200
850
850
780
Centrifuge Force
645/1006
680/806
670/968
700/1008
607
647
612
Motor (kW)
7.5
11
18.5
18.5/22
30
37
37
Dimension (L*W*H) (mm)
1720*1200*1300
2000*1400*1500
2550*1800*1780
2550*1800*1780
2600*2300*1800
3200*2400*2150
3300*2600*2100
Weight (kg)
1500
2500
3800
4000
6000
8500
10000
Production site
Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges

Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges
Psd Automatic Small Top-Suspended Sugar Separation Huada Centrifuges
