Ozone Generator Water Treatment System for Clean Water Pool

Ozone Generator Water Treatment System for Clean Water Pool  Operating PrincipleFirst, place the circulation tank of self-cleaning sterilizer to the lower middle part of the water tank so as to guarantee the even circulation of the tank water. When

Technical Feature

  • Shanghai, China
  • 5000 Sets/Year
  • L/C, T/T, Western Union, Paypal
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$150~8

PRIMARY PARAMETERS

Model NO.
YLD
Dielectric Material
Quartz Tube
Gas
Air
Installation
Wall-Mounted
Performance
Efficient Filtration
Motive Force
Electric Power
Material
Stainless Steel, Carbon Steel
Power Supply
220V-380V
Efficiency
99%
Trademark
YLD
Specification
CE, SGS
HS Code
842121999
Certification
ISO9001, CE
Cooling Method
Water-Cooling
Frequency
400-1000Hz
Type
Ozone Water Purifier
Style
Vertical
Usage
Chemical Industry
Certificate
CE, ISO
Lifespan of Lamp
9000 Hours
Max Pressure
0.6MPa
Transport Package
Plywood Case Into Container
Origin
Jiangyin, Jiangsu, China

DETAIL DESCRIPTION

Ozone Generator Water Treatment System for Clean Water Pool

Operating Principle
First, place the circulation tank of self-cleaning sterilizer to the lower middle part of the water tank so as to guarantee the even circulation of the tank water. When the water level reaches the designed top limit, the electric control cabinet starts up the high-voltage power and the strongly-oxidized gas generated by the immersible pump flows through the pipeline to the aeration section to aerate-disinfect the water, and at the same time, the immersible pump sends the disinfected water back into the water tank to circulate the stagnant water. Thus water circulation continues until thorough disinfection is completed and the water quality is guaranteed. Before delivered off the factory, the time for this product has been set without resetting by the user.

Categorization of Products
1. Water-tank ozone self-cleaning disinfector
2. Water-tank micro-electrolysis self-cleaning disinfector

Working principle for the water- Tank ozone self- Cleaning disinfector:
It functions the way that the oxygen goes through the high-frequency electric field and becomes ozone to be mixed in time with the water and that the strong oxidizing effect of ozone can kill the bacteria in the water. The optimal density in which bacteria are killed can be regulated by changing the pressure of the incoming water, amount of ozone and current, As the ORP of ozone in water is 2.07V, which is higher than 1.36V of chloride, only when the ozone content is 1/1 0000 of the chloride, the bacteria-killing effect is 600-3000 times better than chloride and other disinfectants, and the bacteria can be killed within several seconds.

Applicable Range
The water-tank self-cleaning disinfector has been widely used in such water storage areas as high level cisterns, water storage tanks, living water tanks, clean water pool of sewage treatment works, fire water tanks, fountain springs, waterscape cistern, swimming pools and the water storage pools for such industries as aquatic products, aquaculture, oceanic world and food and beverage.
Ozone Generator Water Treatment System for Clean Water Pool
Ozone Generator Water Treatment System for Clean Water Pool


Model
Volume adaptable for water tanks (pools)

Power (W)
Used for disinfection of secondary water supply (m³)Used for first water
tanks (m³)
WTS-1010-3010-50280
WTS_2030_6050_80350
WTS_3060_15080_200480
Ozone Generator Water Treatment System for Clean Water Pool
