EPS machine of Shape Molding machine advantages:
Economic, High-efficiency, Energy-saving30%,
Steam consumption: (8-10)steam of 1Tmaterial
Successful tests reaffirmed that SPZ-E series automatic shape molding machines obtain the consistent high praise from the customers because of high efficiency, energy saving and stability. The advantages as follows:
1. High-strength frame, mouding frame has being treated with zinc spraying, adopts apposite directions type tie bar for easy maintenance and wear resistance self-lubricating copper tube.
2. Hydraulic pressure system achieves faster operation (save 6S/cycle).
3. Steam system(ensure stable and less steam consumption), adopts FANGYUAN patented PID system made by DN50 actuator makes the sensitive steam pressure control.
4. Pipe system: Completely inlet and exit of water, air and steam adopt big pipeline and valves which is very close to the mold.
5. Vacuum system: Adopting vertical vacuum system, vacuum tank equip with a big spraying system.
6. Control system: All parts adopt famous international brands with high quality. All pressure adjustment are remote controlled by control box, the program also has many self-protection and alarm systems.
Economic, High-efficiency, Energy-saving30%,
Steam consumption: (8-10)steam of 1Tmaterial
Successful tests reaffirmed that SPZ-E series automatic shape molding machines obtain the consistent high praise from the customers because of high efficiency, energy saving and stability. The advantages as follows:
1. High-strength frame, mouding frame has being treated with zinc spraying, adopts apposite directions type tie bar for easy maintenance and wear resistance self-lubricating copper tube.
2. Hydraulic pressure system achieves faster operation (save 6S/cycle).
3. Steam system(ensure stable and less steam consumption), adopts FANGYUAN patented PID system made by DN50 actuator makes the sensitive steam pressure control.
4. Pipe system: Completely inlet and exit of water, air and steam adopt big pipeline and valves which is very close to the mold.
5. Vacuum system: Adopting vertical vacuum system, vacuum tank equip with a big spraying system.
6. Control system: All parts adopt famous international brands with high quality. All pressure adjustment are remote controlled by control box, the program also has many self-protection and alarm systems.
| SPZ100-200T Automatic Shape Molding Machine with Vacuum (Typical) | ||||||||
| Item | Unit | SPZ100 T | SPZ120 T | SPZ140 T | SPZ160 T | SPZ175 T | SPZ180 T | SPZ200 T |
| Mould Dimension | mm | 1000*800 | 1200*1000 | 1400*1200 | 1600*1350 | 1750*1450 | 1800*1600 | 2040*1800 |
| Max Product Dimension | mm | 800*600* *330 | 1000*800 *330 | 1200*1000 *330 | 1400*1100 *330 | 1550*1200 *330 | 1610*1400 *330 | 1850*1600 *330 |
| Stroke | mm | 210-1360 | 210-1360 | 270-1420 | 270-1420 | 270-1420 | 220-1370 | 290-1290 |
| Steam Entry | mm | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| Steam Consumption | kg/cycle | (10-13T) Steam of 1T material | ||||||
| Water Entry | mm | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| Cooling Water Consumption | kg/cycle | 40-120 | 45-138 | 50-150 | 55-180 | 60-190 | 80-200 | 90-210 |
| Compressed Air Entry | mm | 40 | 40 | 40 | 40 | 40 | 50 | 50 |
| Compressed Air Consumption | m3/cycle | 1.2 | 1.5 | 1.8 | 2 | 2 | 2.2 | 2.5 |
| Vacuum Pump Capacity | m3/h | 165 | 165 | 230 | 280 | 280 | 280 | 280 |
| Connected Load | KW | 10.6 | 10.6 | 14.1 | 19.6 | 19.6 | 23.6 | 23.6 |
| Overall Dimension | mm | 4500*1640 *3900(mm) | 4500*1840 *410000(mm) | 4600*2140 *4300(mm) | 5000*2300 *4600(mm) | 5000*2450 *4700(mm) | 5100*2610 *5000(mm) | 4900*2800 *5200(mm) |
| Machine Weight | kg | 4500 | 5200 | 5700 | 7000 | 7500 | 8000 | 8500 |
| Cycle Time | s | 60-90 | 60-100 | 60-150 | 90-160 | 90-160 | 120-190 | 130-210 |
