1. Volume (length× width ×height):
370mm×340mm ×1570mm
2.  Weight: about 90kg
3. Power supply voltage:
AC220V/110V  50HZ / 60 HZ ,Power: 1500W

4.  Blood pump/spare pump:
    ?Flux: 15 ~ 340ml/min (D 6mm)
           20 ~ 460 ml/min (D 8mm)
5. Heparin pump:
    ?Flux: 0ml/h~10ml/h(±5%)
    ?Precise: 0.1ml/h
    Injector size: 20ml/30ml/50ml
                10ml/20ml/30ml (selectable)
6.  Arterial pressure:
   ?display scope:-300mmHg~+300mmHg
                           (±10mmHg)
7.  Venous pressure:
   ?display scope:-50mmHg~+300mmHg
                           (±10mmHg)

8.  Dialysate flow:
   300ml/min~800ml/min linearity adjustable  (+10%) (-5%)
   Temperature:35.0ºC~39.0ºC
   Resolving rate:0.1ºC
   Conductivity:13mS/cm~15.5mS/cm   (±0.1 mS/cm)

9. UF flow scope: 0~1800ml/h(±30ml/h )
                 0~4000ml/h(optional)
10. ISO UF flow scope:0~2000ml/h(±30ml/h)
11. TMP:  Scope:-100mmHg~+600mmHg   (±20mmHg)
12.  Blood leakage monitor:
    over 1ml blood per liter dialysate  (flow:500ml/min)
13. Blood level monitor: ultrasonic sensor
14.  Air bubble monitor:
    Infrared and response threshold value:
    Single air bubble of 200 I exists when
     Blood flux is 200ml/min
15.  Inflow pressure:0MPa~0.6MPa
16.  Inflow temperature: 5ºC~30ºC
17.  Environment temperature: 10ºC~30ºC,
     Relative humidity≤70%
18. Rinse/disinfection: chemical disinfection
    (citric acid,peracetic acid and oxalic acid)

19. Hot rinse: 80ºC
20. Back-up power supply: last for 15-30min after electric-cut.
