Stainless Steel Tube Finned Ammonia Evaporator

Cooling coil Specific wholly rippled street fin, fin spacing 5,8,10,12,16mm Stell tubes φ20mm.Tube pattern60x52mm staggered.Hot-dip galvanized,and tested with gas pressure test of 2.4MpaFanBlow-through type or draw-air-in type outer rotor axial fan

Technical Feature

  • 9000 Unit/Units / Month
  • Customerized Packing
  • T/T, Western Union
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~70

PRIMARY PARAMETERS

Model NO.
CD-400
Refrigerant
R22,R410A, R407c...
Material
Copper
Heat Transfer Mode
Recuperative
Application Field
HVAC & Refrigeration
Condition
New
Fin Material
Stainless Steel
Fin Surface
Bare Fin
Fin Thickness
0.105mm-0.4mm
Tube Type
Thread Tube
Usage
for Refrigerate, for Air Conditioner, for Manufa
Specification
ROHS, ISO, SGS
HS Code
8415909000
Condensation Forms
Air-Cooled
Type
Water and Gas Condenser
Structural Form
Horizontal
Form
Tube Fin Heat Exchanger
Certification
RoHS, ISO
Tube Material
Stainless Steel
Design Serice
Be Viable
Plate Material
Stainless Steel
Liquid Flow Rate
2.5m/S
Maximum Working Pressure
3.0MPa
Trademark
Shenglin
Origin
Shanghai, China

DETAIL DESCRIPTION

Cooling coil
 Specific wholly rippled street fin, fin spacing 5,8,10,12,16mm Stell tubes φ20mm.Tube pattern60x52mm staggered.Hot-dip galvanized,and tested with gas pressure test of 2.4Mpa


Fan
Blow-through type or draw-air-in type outer rotor axial fan Motor protection up to IP54,and can be run continuously from -50ºC to 100ºC.electrical supply:380V/50HZ/3φ. Electrical is determined against the axial fan model.

Casing
   Galvanized steelsheets used. Rational processing technology is used to secure high intensity bump proof casing.
    Good removablity with side plate, front plate and back plate.
    Surface steel sheets are painted with fine stoving finish or other finish..

Drip tray
    Wholly plastic spraying and rust-proof threated. Portable construction,good removability.drain pipes are joined by built-in threads.

Defrosting
Water defrosting, hot refrigerant defrosting, e-heating defrosting and combination defrosting.

Package:
Special export wooden package is suitable for sea transportation.

Optional design:
Special Refrigeration (Exceopt R717 and R22): such as ethylene glycol
Special fin spacking or combination within the scope of 6-14mm
Epoxy Al fin
Stainless Steel Casing
Plastic coating casing
Duct Fan
Explosion-proof Fan


Product application ranges:

1.Commercial air conditioner

2.Refrigerator

3.Transportation
4.Fan coil

5.Display cabinet

6.Refrigerated vehicle
7.Air conditioner's handling unit

8.Ice maker

9.Refrigerated container
10.Moisture eliminator

11.Drink machine

12.Other industry, such as Desalination, chemical etc

Stainless Steel Tube Finned Ammonia Evaporator




MODEL
SIZE

(MM)
HEATING

AREA

(M2)
HP
PATTERN
INLET

( MM)
OUTLET

(MM)
CAPACITY

(KW)
FIN

PITCH

(MM)
FIN

LENGTH

(MM)
FAN
VOLTAGE

(V)

CD-2
320*100

*235
2
1/4
2*4
3/8
3/8
0.6
2.35
270
200
220

CD-3.4
320*100

*235
3.4
3/8
3*4
3/8
3/8
1
2.1
270
200
220

CD-4.4
370*100

*285
4.4
1/2
3*5
3/8
3/8
1.3
2.4
325
250
220

CD-5.4
440*100

*330
5.4
3/4
3*6
3/8
3/8
1.6
2.85
392
300
220

CD-7
440*135

*330
7
1
4*6
12
12
2
2.9
390
300
220

CD-8.4
500*130

*430
8.4
1.2
3*8
16
12
2.3
2.8
455
300
220/380

CD-11.5
480*180

*430
11.5
1.5
4*8
16
12
3.5
2.6
430
350
220/380

CD-15
550*180

*480
15
2
4*9
16
12
4.4
2.55
490
350
220/380

CD-18
590*180

*530
18
2.5
4*10
19
16
5.2
2.55
530
350
220/380

CD-22
590*180

*530
22
3
5*10
19
16
6.4
2.6
530
350
380

CD-25
750*180

*680
25
3.5
4*11
19
16
8.1
3
660
400
380

CD-21
840*180

*430
21
3
3*8
16
12
6.1
1.95
790
300*2
380/220

CD-28
900*180

*430
28
3.5
4*8
19
16
8.2
2.1
840
350*2
380

CD-33
900*200

*480
33
4
5*9
19
16
11.2
2.45
840
350*2
380

CD-36
1015*180

*580
36
5
4*11
22
19
12.6
2.5
950
400*2
380

CD-43
1015*180

*680
43
6
4*13
22
19
14.8
2.5
950
400*2
380

CD-48
1250*200

*630
48
6.5
4*12
25
22
17.5
2.5
1172
400*2
380

CD-55
1250*200

*730
55
7.5
4*14
22
19
19.2
2.59
1172
400*2
380

CD-70
1250*200

*830
70
10
4*16
22
19
20.5
2.3
1172
300*4
380

CD-80
1250*200

*930
80
12
4*18
25
22
24.4
2.3
1172
400*4
380

CD-100
1250*200

*1130
100
13
4*22
25
22
29.6
2.2
1172
400*4
380

CD-130
1250*200

*1380
130
15
4*27
25
22
38.2
2.1
1172
400*4
380

CD-150
1250*250

*1330
150
20
5*26
25
22
47.2
2.3
1240
500*4
380

CD-180
1250*270

*1330
180
25
6*26
25
22
58
2.3
1240
500*4
380

CD-210
1720*255

*1230
210
30
6*24
32
25
69.5
2.4
1650
400*6
380


Mold of Stainless steel tube&aluminum fin/copper fin


Fin PatternStainless steel Tube O.D.(mm)Row Space
(mm)		Hole Space
(mm)		Fin Thickness
(mm)		Fin Space(mm)
Flat finSine wave with blade finSmooth sine wave finWindow
fin		Sesamoid fin
A9.522225.40.105~0.151.6~3.21.6~3.21.6~3.21.6~3.2/
B9.5216.519.050.105~0.1151.4~2.51.4~2.51.4~2.5//
C12.7527.531.750.115~0.151.5~3.51.5~3.51.5~3.51.5~3.51.6~3.2
D15.883338.10.115~0.151.5~4.01.5~4.01.5~4.0//
