Lw Horizontal Continuous Decanter Centrifuge

Decanter Centrifuge

Technical Feature

  • 1 Set
  • Shanghai, China
  • 100 Sets/Month
  • L/C, T/T, Western Union
  • Centrifuge
  • Solid Liquid Separation Centrifuge
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~0

PRIMARY PARAMETERS

Model NO.
LW
Condition
New
Control
PLC Control
Model
Decanter Centrifuge
Moc
Ss321/316L
Motor
Frequency Control
Guarantee
12 Month
Discharge
Automatic Continuous Scroll Discharge Decanter
Automation
Automatic Decanter Centrifge
Operation
Continuous Decanter Centrifuge
Usage
Industrial
Product Type
Chemcial
Trademark
Huada
Transport Package
Standard with Wooden Pallet and Poly Film Wrapping
Specification
CE
Origin
China
HS Code
8421199090

DETAIL DESCRIPTION

Decanter Centrifuge


Product Description



Lw Horizontal Continuous Decanter Centrifuge


Labyrinth seal is used for both bowl ends of LW standard type decanter centrifuge, simple and convenient, after separation, the solid phase is conveyed to the solid discharge port by scroll conveyor, and discharged out of centrifuge under centrifugal force caused by high speed rotation; while the liquid phase drains out under gravity and centrifugal force through the overflow plate. This series decanter centrifuge features easily operation, continuous and stable running, and wide application scope.


Operating principle

Decanter Centrifuge Operation Video:

http://www.huada-video.com/lw-decanter

Lw Horizontal Continuous Decanter Centrifuge


Separation takes place in a horizontal bowl equipped with a scroll conveyor. The process material is fed into the bowl through a stationary inlet tube and is smoothly accelerated in the accelerate chamber. Centrifugal forces cause instant sedimentation of the solids on the wall of the bowl. The conveyor rotates in the same direction as the bowl, but at a different speed, thus moving the solids towards the conical end of the bowl.
Applications



LW series decanter centrifuge is a horizontal centrifuge with continuous feeding and continuous discharging. It has two-phase (solid-liquid) separation and three-phase (solid-liquid-liquid) separation.

Main applications:
Industrial and municipal wastewater treatment
Oil & gas drilling mud/fluid control
Washing, classification and dewatering of amylum and starch
Mycelium separation from zymotic fluid of antibiotic
Dewatering of soybean and wheat protein
Dewatering of fish power and fish meet
Dewatering of grains
Clarification and extraction of fruit juice
Clarification and purification for animal and vegetable oil
Production and extraction of olive oil, palm oil, avocado oil
Separation and purification for coal tar
Grading of kaolin and graphite
Classification and dewatering for dyestuff and pigment
Float wash of extractive coal and dewatering of coal mud
Classification and dewatering for minerals


Main Features
Vertical base design and symmetrical arrangement of motor and bowl assembly, that ensures stable operation and less vibration.
Main parts such as the bowl and conveyor are made of corrosion-resistant stainless steel or duplex steel, offering high maximum bowl speed and high centrifugal force.
Dual motor drive makes bowl speed and conveyor speed adjustable.
Screw conveyor flights tiled or lined with ceramic, tungsten carbide, or other hard alloys.
Optional planetary gearbox and hydraulic gearbox, offering wide range of differential speed adjustment.
Multiple safety protection: bowl speed and differential speed detection, over-vibration protection, motor overload and overheat protection, bearing temperature monitoring, conveyor torque protection and gas-tight explosion-proof protection.
JG type rubber vibration isolator, no need of anchor bolts.

Wear protection

Lw Horizontal Continuous Decanter Centrifuge


1.Scroll with welded hard facing or spray coating
2.Scroll Inlaid with tungsten carbide tiles
3.Bowl inner wall welding with high strength wear resistant strips




Lw Horizontal Continuous Decanter Centrifuge


Solid discharge port

1.Tungsten carbide or ceramic bushing
2.Simple structure and easily replacement
3.LOW maintenance cost

Optional system
The hydraulic conveyor driving is a closed driving system, including the centrifuge bowl and conveyor. It is independent from the bowl driving. The hydraulic conveyor driving is different from other mechanical conveyor driving system which relies on bowl rotating to generate differential speed. The hydraulic driving device is directly mounted on the conveyor assembly, and is driven by hydraulic pump aggregate. Therefore it is independent from the bowl driving system.

Lw Horizontal Continuous Decanter Centrifuge


Operating principle

The hydraulic conveyor gearbox is connected with the bowl of the decanter centrifuge, both of them rotates in high speed. The spline shaft on the gearbox rotor is connected with the conveyor, and rotates in different speed driven by the high pressure oil, that's we call the differential speed. The conveyor gearbox is connected with the hydraulic pump by flexible hose, so there is no need of gearbox between the bowl and conveyor. Conveyor torque gives pressure to the hydraulic system. With the action of such pressure, the different speed can by adjusted by adjusting the oil supply and flow rate.



Main features

No gear driving device required
No damage to the parts due to overload
Free of torque vibration (fluttering)
Direct readable torque and differential speed △n
△n independent from bowl speed
Minimum moisture content of sludge

High clarification of liquid phase
Power for solid conveying varying from solid loads
Dewatering varying from changes in △n
"Constant" moisture content of sludge
Non-sensitive to feeding quantity, minimize blockage
Safety pin design ensuring safe operation


Parameters
Models
Bowl Diameter (mm)
L/D Ratio
Bowl Speed (r/min)
G-force
Main Motor Power (kW)
Weight (kg)
Dimension (L*W*H) (mm)
LW220*880
220
4
4800
2840
7.5-11
1000
2658*740*781
LW355*1460
350
4.17
4000
3100
22
2020
3542*1010*1030
LW450*1800
450
4
3200
2577
30-37
3500
4122*1090*1250
LW450*2025
450
4.5
3200
2577
30-37
3800
4560*1090*1250
LW530*2120
530
4
2800
2327
45-55
4200
4728*1230*1455
LW530*2650
530
5
2500
2150
37-55
4500
5050*1230*1350
LW630*2300
630
3.65
2500
2205
75
8000
5110*1440*1750
LW650*2800
650
4.3
2500
2270
90
9600
5380*1719*1560
LW1000*3000
1000
3
1500
1258
132
16000
5180*2500*1950

Lw Horizontal Continuous Decanter Centrifuge
