Platform Bag Lifting Top Discharge
Centrifuge
_______________________________________________________________________________
Manual Top Discharge Centrifuge in Production Video:
http://www.huada-video.com/PSD-Series
Once the materials to be separated enter the fast-spinning basket, it will be filtrated by the filter liner under the centrifugal force. The liquid flows out through the liquid outlet, but solids deposit on the internal wall of the basket. Once the solid cake reaches the rate capacity, feeding stops. Wash the solids cake, and then drain out the washing water. Finally stop the machine. Use the lifting tool or crane to lift out the filter cloth with solid cake, and move to the discharging place. Open the filter cloth and discharge the solid cake. Put the filter cloth back to the centrifuge and move to next batch.
1,Inverter start-up, smooth starting, adjustable relative centrifugal force.
2,Discharge cake by lifting out filter cloth is highly efficient with low labour intensity; No damage to the particles; Wide range of applications.
3,Well-designed structure and polished surface leaves no residual heel. With big hinged cover, it is easy to clean the gap between the case and the basket.
4,Overall welding structure between the base and the case ensures high carrying strength.
5,Platform base design lowers the center of gravity and requires minimum installation space. The platform base can be used for operation platform.
6,Liquid-damping vibration isolators, simplify the routine maintenance.
7,Big hinged cover, feed pipe, wash pipe, observation glass and light.
8,Automatic CIP system cleans the internal surface of the case, the basket and liquid slot to meet the clean requirement in accordance with GMP standards.
9,Tightness structure with silicone rubber or fluoroelastomers seals. Nitrogen protection system(optional)is for anti-explosion applied to poisonous, flammable and explosive environment.
10,Equipped with hydraulic suspension arms with external fully-stainless steel surface (optional), which is easy for discharging and complies with the sanitation requirements.
Items | Models | ||||||
PSD800 | PSD1000 | PSD1200 | PSD1250 | PSD1500 | PSD1600 | PSD1800 | |
Basket Dia (mm) | 800 | 1000 | 1200 | 1250 | 1500 | 1600 | 1800 |
Basket Volume (L) | 120 | 200 | 330 | 400 | 600 | 800 | 910 |
Max. Load (kg) | 150 | 250 | 410 | 500 | 800 | 1000 | 1100 |
Max. Rotating speed (r/min) | 1200/1500 | 1100/1200 | 960/1050 | 1000/1200 | 850 | 850 | 780 |
Centrifuge Force | 645/1006 | 680/806 | 670/968 | 700/1008 | 607 | 647 | 612 |
Motor (kW) | 7.5 | 11 | 18.5 | 18.5/22 | 30 | 37 | 37 |
Dimension (L*W*H) (mm) | 1720*1200*1300 | 2000*1400*1500 | 2550*1800*1780 | 2550*1800*1780 | 2600*2300*1800 | 3200*2400*2150 | 3300*2600*2100 |
Weight (kg) | 1500 | 2500 | 3800 | 4000 | 6000 | 8500 | 10000 |
